12.7 Input Connector Ratings

12.7 Input Connector Ratings
Connections
Insulation
12.8

Instrument Interface

12.8.1

Front Panel Indicators and Controls

Status LEDs
Display
Keypad
12.8.2

External Interface Connections

Serial
Connectors
12.8.3

Programmable Contact Output Connections

Two types of programmable relays are offered with the 1133A: standard mechanical, Form-C
(SPDT) and optional solid-state, Form-C for use with KYZ pulse metering. Use protective measures
when using optional KYZ-rated contacts to guard against surges that will damage the contacts if
ratings are exceeded. See "Configuring Multimode Relays" in Section 7.10, for details on configuring
contacts.
Removable screw-clamp terminal block, accepting 0.2
(AWG 24-10) solid or stranded conductors
400 V, nominal, to neutral/chassis, surge voltage class III
600 V, nominal, to neutral/chassis, surge voltage class II
Contact factory for more detailed information
Operate (green)
Time Set (green)
Unlocked (red)
Fault (red)
2 X 20 character LCD display
8 button, for status only (for configuration, see Chapter 7)
Two, RS-232 or RS-485 half-duplex or modem (V.34bis,
33.6k) optionally available for each port
Two, RJ-11 modular;
One, RJ-45 modular Ethernet: 10base-T per IEEE 802.3I
127
2
4 mm
