V1505-E4B-KEA-1 -> ENGINE -> 010200 PISTON AND CRANKSHAFT ## V1505-E4B-KEA-1
No Part Number
010 1J097-21110 PISTON
010 1J097-21910 PISTON(05)
020 1J050-21050 RING,PISTON,ASSY
020 1J050-21090 RING,PISTON,ASSY 05
030 16241-21310 PIN,PISTON
040 16241-21330 CIRCLIP(PIN,PISTON)
ROD,CONNECTING,ASS
050 16292-22016
Y
060 1G700-21980 BUSH,PISTON PIN
BOLT(CONNECTING
070 16241-22142
ROD)
080 16292-22310 METAL(PIN,CRANK)
080 16292-22972 METAL,CRANKPIN
080 16292-22982 METAL,CRANKPIN
090 1G871-23016 COMP.CRANKSHAFT
120 1A055-24110 GEAR(CRANKSHAFT)
130 16271-95230 KEY
140 1J050-35630 GEAR(OIL PUMP DRIVE)
150 16241-23280 SLEEVE,CRANKSHAFT
160 1J050-23250 COLLAR(CRANKSHAFT)
170 04814-10280 RING
180 16292-23473 METAL(CRANKSHAFT)
180 16292-23913 METAL(CRANKSHAFT)
Update Date: 03/06/2015, Printing Date: 09/03/2016
Interchangeable =, Not Interchangeable NI, New for Old >>, Old for New <<
Part Name Qty
4
4
4
4
4
8
4
4
8
4
4
4
1
1
1
1
1
1
1
1
1
IC S/N
STD
+0.50mm
STD
+0.50mm
STD/SET
-0.20mm/SET
-0.40mm/SET
STD
-0.20mm
Remarks Kg
0.414
0.425
0.04
0.032
0.135
0.002
0.526
0.01
0.024
0.04
0.033
0.034
10.45
0.142
0.005
0.09
0.06
0.047
0.001
0.046
0.005
