Operating Instructions
PP
4.7

Technical data

Model:
Drive power:
Engine:
Cylinder capacity:
Equivalent permanent sound level LpA:
Vibration values:
Effective acceleration value acting on the upper limbs:
Effective acceleration value acting on the body:
Undercarriage:
Speed control:
Speeds:
Driving setting 0
Driving setting 1
Weights & Measurements:
Max. total weight:
Dead weight:
Hopper volume:
Transportation measurements (Compact):
Carrying capacity:
On-board voltage:
Installation depth (sub-base height)
Filling capacities:
Fuel tank:
Engine oil:
Hydraulic fluid:
Operating fluids:
Fuel:
Engine oil:
Hydraulic fluid:
Lubricating grease:
24 / 73
General information
POWER PLAN PP
18,5 kW (25,2 HP)
Diesel engine V1505-E4-B
Please refer to the engine (KUBOTA) and combined cooler's
(EMMEGI) operating manuals for their technical data
1.498 cm³
82 dB[A]
< 2.5 m/s²
< 0.5 m/s²
Crawler tracks
Please refer to the crawler undercarriage's (TFW) operating
manual for the technical information
Continuous hydrostatic drive
1.6 km/h
3.2 km/h
6,000 kg (13,200 lbs)
2,500 kg
approx. 2.5 m³
1.900 x 2.050 x 3.400 mm (75"x81"x134") (H x B x L)
3,500 kg (7,700 lbs)
12 V DC
16 cm
30 litres (tank filling is sufficient for ca. 8-10 working hours)
6 litres
30 litres
Diesel (Ultra low sulfur diesel fuel
[sulfur content < 0.0015% (15 ppm)]
DO NOT USE BIO DIESEL.
SAE 15W-40 / API-CF4
HLP46 (hydraulic fluid as specified under ISO 2943)
RKM filter, 100/15 µm (filter mesh)
Conventional high-performance multi-purposes grease
V4 GB
