- Page 1 Operating Instructions Translation of original operating instructions Manhole and cone chain clamp SRG SRG-1,5/SRG-3/SRG-3-L 5440.0001/5440.0002/5440.0003...
- Page 2 Bitte beachten Sie, dass das Produkt ohne vorliegende Betriebsanleitung in Landessprache nicht eingesetzt / in Betrieb gesetzt werden darf. Sollten Sie mit der Lieferung des Produkts keine Betriebsanleitung in Ihrer Landessprache erhalten haben, kontaktieren Sie uns bitte. In Länder der EU / EFTA senden wir Ihnen diese kostenlos nach.
-
Page 3: Table Of Contents
Operation ................................12 Maintenance and care ............................14 Maintenance ..............................14 MECHNICAL ..............................14 Trouble shooting ............................15 Repairs ................................16 Safety procedures ............................16 Hints to the type plate ........................... 17 Hints to the renting/leasing of PROBST devices ..................17 2 /17... -
Page 4: Ec-Declaration Of Conformity
DIN EN 349 Minimum distance to avoid squeezing any parts of the body (ISO 13854). Authorized person for EC-dokumentation: Name: J. Holderied Address: Probst GreiftechnikVerlegesysteme GmbH; Gottlieb-Daimler-Str. 6; D-71729 Erdmannhausen Signature, informations to the subscriber: Erdmannhausen, 30.07.2015................(M. Probst, Managing director) -
Page 5: General
Operating Instructions General SRG-1,5/SRG-3/SRG-3-L 2 General Authorized use ● The device is only designed for the use specified in this documentation. ● Every other use is not authorized and is forbidden! ● All relevant safety regulations, corresponding legal regulations, especially regulations of the declaration of conformity, and additional local health and safety regulations have to be observed. -
Page 6: Survey And Construction
Operating Instructions General SRG-1,5/SRG-3/SRG-3-L Survey and construction Eyelet Chain Manhole Technical data Order-No.: Carrying capacity Gripping Range of Claws Nominal Value ID of cones and manholes 5440.0001 SRG-1,5 1.500 kg 40-120 mm 400-2,000 mm (3,300 lbs) (1½ – 4¾”) (15¾ – 79”) 5440.0002 SRG-3 3,000 kg... -
Page 7: Safety
Operating Instructions Safety SRG-1,5/SRG-3/SRG-3-L 3 Safety Safety symbols Danger to life! Identifies imminent hazard. If you do not avoid the hazard, death or severe injury will result. Hazardous situation! Identifies a potentially hazardous situation. If you do not avoid the situation, injury or damage to property can result. -
Page 8: Safety Marking
Operating Instructions Safety SRG-1,5/SRG-3/SRG-3-L Safety Marking PROHIBITION SIGN Symbol Meaning Order-No.: Size: 2904.0210 30 mm It is not allowed to be under hanging loads. Danger to life! 2904.0209 50 mm 2904.0204 80 mm WARNING SIGN Symbol Meaning Order-No.: Size: 2904.0221 30 mm Danger of squeezing the hands. -
Page 9: Personal Safety Requirements
Operating Instructions Safety SRG-1,5/SRG-3/SRG-3-L Personal safety requirements ● Each operator must have read and understood the operating instructions. ● Only qualified, authorized personal is allowed to operate the device and all devices which are connected (lifting equipment). ● The manual guiding is only allowed for devices with handles. Protective equipment <... -
Page 10: Safety Procedures
Operating Instructions Safety SRG-1,5/SRG-3/SRG-3-L Safety procedures 3.4.1 General ● The use of the device is only permitted in proximity to the ground. Do not swing it over people heads. ● The manual guiding of the device is only allowed at the handles. ●... -
Page 11: Installation
Operating Instructions Installation SRG-1,5/SRG-3/SRG-3-L 4 Installation Mechanical connection Load hook and chains ● Fit suspension ring in the load hook of the lifting equipment/carrier. ● Ensure that the single chains are not twisted and may be easily pulled through the jaws ●... -
Page 12: Adjustment Of The Opening Width
Operating Instructions AdjustmentsAdjustments SRG-1,5/SRG-3/SRG-3-L Adjustment of the opening width Open jaw by turning the adjusting screw. Do not exceed the maximum opening width as the nut of the adjusting screw is not secured. Safety hazard ! Place jaws - angle lever facing inwards - onto the manhole . Now push downwards angle lever against the spring resistance to the limit stop . -
Page 13: Operation
Operating Instructions Operation SRG-1,5/SRG-3/SRG-3-L 6 Operation ● The manholes must be of sufficient construction to withstand clamping force during transport. ● Only transport sufficiently cemented and fracture-free manholes / conical manholes, otherwise there is a danger of the load, or part of it falling ! ●... - Page 14 Operating Instructions Operation SRG-1,5/SRG-3/SRG-3-L Transport of cones ● ● To transport symmetrically conical manholes turn all jaws As far as asymmetrically conical manholes are concerned about an angle of 180° to prevent the chain running over turn only one jaw about an angle of 180° and adjust its the top edge.
-
Page 15: Maintenance And Care
Operating Instructions Maintenance and care SRG-1,5/SRG-3/SRG-3-L 7 Maintenance and care Maintenance To ensure the correct function, safety and service life of the device the following points must be executed in the maintenance interval. Used only original spare parts, otherwise the warranty expires. All operations may only be made in closed state of the device! For all operations you have to make sure, that the device will not close unintended. -
Page 16: Trouble Shooting
Operating Instructions Maintenance and care SRG-1,5/SRG-3/SRG-3-L Trouble shooting ERROR CAUSE REPAIR The clamping-power is not big enough, the load is slipping out (optional) The grippers are worn Replace the grippers (optional) The maximum load is exceed Reduce the weight of. -
Page 17: Repairs
Operating Instructions Maintenance and care SRG-1,5/SRG-3/SRG-3-L Repairs ● Only persons with the appropriate knowledge and ability are allowed to repair the device. ● Before the device is used again, it has to be checked by an expert. Safety procedures It is the contractors responsibility to ensure that the device is checked by an expert in periods of max. -
Page 18: Hints To The Type Plate
Example: Hints to the renting/leasing of PROBST devices With every renting/leasing of PROBST devices the original operating instructions must be included unconditionally (in deviation of the users country's language, the respective translations of the original operating instructions must be delivered additionally)! - Page 20 After each completed performance of a maintenance interval the included form must be fill out, stamped, signed and send back to us immediately 1) via e-mail to service@probst.eu / via fax or post Operator: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _...
- Page 21 After each completed performance of a maintenance interval the included form must be fill out, stamped, signed and send back to us immediately 1) via e-mail to service@probst.eu / via fax or post Operator: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _...
- Page 22 After each completed performance of a maintenance interval the included form must be fill out, stamped, signed and send back to us immediately 1) via e-mail to service@probst.eu / via fax or post Operator: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _...
