TRANSPORT MOUNTING PANEL

KIT CONTENTS

The Transport Mounting Plate kit (VersaMed Part Number 900K0015-01, GE Part
Number M1169908) includes:
ITEM NO.
1
2
3
4
5

INSTALLATION

1.
2.
3.
4.
5.
6.
7.
DESCRIPTION
Transport Mounting plate
Screws
Flat washers
Spring washers
Spacers (for Disaster
Preparedness devices only)
Turn off the ventilator and disconnect the power cable and patient circuit
tubing from it.
Flip the ventilator upside-down.
Note: If an old model with an old mounting plate (VersaMed P/N. 325A0162-A3,
GE P/N. M1161827) is attached to the ventilator, release the 4 screws that hold
the old model of the Mounting plate, and remove it (See Figure 190).
For Disaster Preparedness models only: Screw the four spacers (item no. 5) into
place, using a #6mm socket wrench (See Figure 191).
Lay the Transport mounting plate (item no. 1) on the ventilator (see Figure 192).
Place a spring washer (item no. 4) and flat washer (item no. 3) on each of the
screw holes on the plate (See Figure 193).
Insert a screw (item no. 2) into each of the screw holes, and screw the four
Philips screws with a Philips screwdriver.
Stand the ventilator upright (standing on the Transport mounting plate).
259
Appendix G: Accessories
DIMENSIONS QUANTITY
305.5 x 117mm 1
M3 x 10mm 4
4
4
M3x10mm 4
