1 Installing the Router
• Using a sharp object, press the RST pushbutton and hold it down.
• Turn on the device with the ON/OFF switch.
• Wait until the WLAN LED begins to flash (see
The WLAN LED flashes
Fig. 20:
• After about 15 seconds, the WLAN LED goes out and the DSL LED lights up (see
pushbutton held down.
The WLAN LED goes out and the DSL lights up
Fig. 21:
• After about 3 seconds, the WLAN LED lights up, this time it's steady i.e. not flashing (see
the DSL goes out. Release the reset button at this point.
The WLAN LED lights up without flashing and the DSL goes out.
Fig. 22:
• Wait for a few seconds until the device completes start up. If you have a local console connected to the CONF.
port, you can see that the device has booted with the default parameters from the BOOT configuration and has
paused start up in the BOOT menu (CFE> prompt):
CFE version 1.0.37-102.9-01 for BCM96358 (32bit,SP,BE)
Build Date: Fri Dec
Copyright (C) 2000-2008 Broadcom Corporation.
Parallel flash device: name AM29LV320MT, id 0x2201, size 16384KB
CPU type 0x2A010: 300MHz, Bus: 133MHz, Ref: 64MHz
CPU running TP0
Total memory: 67108864 bytes (64MB)
Boot Address 0xbe000000
*** Break into CFE console ***
Use default boot line parameters: e=192.168.1.1:ffffff00 h=192.168.1.100 g= r=f f= i= d=3 p=0
DHCP running
Board IP address
Host IP address
Gateway IP address
Run from flash/host (f/h)
Default host run file name
Default host flash file name
Boot delay (0-9 seconds)
Boot image (0=latest, 1=previous) : 0
Board Id (0-0)
Number of MAC Addresses (1-32)
Base MAC Address
PSI Size (1-64) KBytes
14
Fig. 20
4 12:10:54 CET 2009 (jsirodey@orion)
: 192.168.1.1:ffffff00
: 192.168.1.100
:
: f
:
:
: 3
: 96358C1PL
: 4
: 00:a0:26:6e:00:58
: 24
on page 14). Keep the RST pushbutton held down.
Fig. 21 on page 14); keep the
Fig. 22 on page 14) and
