Q'STRAINT QUANTUM Installation Manual page 45

CHECK
Driver Interface,
Master Switch
"OFF"
OFF
Driver Interface
Master Switch
"OFF", Occupant
Switch Works OFF
Master Switch
Master Switch
"OFF", Occupant
Interface Disabled
Master Switch "OFF",
2nd Occupant
Interface Disabled
Driver Interface
Master Switch
"ON", Cycle Unit ON
from Driver
Interface
Master Switch
Master Switch "ON"
or "OFF", Occupant
Interface LED Light
"ON"
Master Switch
"ON", Cycle Unit
from Occupant
Interface
Master Switch
"ON" or "OFF",
2nd Occupant
Interface LED
Light "ON"
Master Switch
"ON", Cycle
Unit from 2nd
Occupant
Interface
MAINTENANCE AND CARE
Remove All Debris From Unit
ONLY
use Soap and Water to Clean the QUANTUM®, Arm
Extensions and Backrest, then Rinse and Dry (Arms Fully
Extended)
Rub 3-in-One® Oil on Arm Extensions
(Do NOT use another brand)
PREVENTATIVE MAINTENANCE CHECKLIST
IMAGE WORKING
No Light
Occupant Switch
Release
Secure
Occupant Switch
NOT
FIXED
WORKING
DONE
45
COMMENTS
Press Secure and center PSI scale between
QUANTUM® Arms. Once scale is secured, press
release.
Press Occupant Interface and center PSI Scale
between QUANTUM® Arms. Once scale is secured,
press Occupant Interface again.
Press 2nd Occupant Interface and center PSI Scale
between QUANTUM® Arms. Once scale is secured,
press 2nd Occupant Interface again.
COMMENTS
Press Occupant Interface, when Rotational Arm moves from
vertical to horizontal position press Occupant Interface again
to stop Arm. When done, press Occupant Interface.
