USER INSTRUCTIONS

Advertisement

loading

Related Manuals for Q'STRAINT QRT-1 Series

Summary of Contents for Q'STRAINT QRT-1 Series

  • Page 1 USER INSTRUCTIONS...
  • Page 2 SECURE WHEELCHAIR 1. Place wheelchair facing forward in securement area; apply wheel locks or turn power off. 2. Attach tie-downs into floor anchorages (Fig. 1) and ensure they are locked in. 3. Attach the four tie-down hooks to solid frame members or weldments, near seat level.
  • Page 4 SECURE PASSENGER 1. Attach Lap Belts - Use integrated stiffeners to feed belts through openings between seat backs and bottoms, and/ or armrests to ensure proper belt fit around occupant. a. On the aisle side, attach belt with female buckle to rear tie-down pin connector (Fig.
  • Page 6 RELEASE PASSENGER 1. Carefully remove passenger’s shoulder and lap belts (Reverse Step B above). 2. Unhook front and rear tie-downs from wheelchair by pressing red release levers on retractors, or activating any remote release or time-delay equipment. 3. Unlock wheels or turn power on, and direct or move passenger out of wheelchair securement area.

  • Page 7: Maintenance And Care

    MAINTENANCE & CARE • Always keep belts clean and off the floor by using a storage device such as the Q’Straint wall pouch. One (1) storage device per wheelchair location is recommended. • All systems and components should be regularly inspected, cleaned, and maintained.
  • Page 8 Having trouble with hard-to-reach securement points? Webbing Loops. Q’Straint recommends our (Part #Q5-7580) Webbing Loops are the perfect solution when securement points on wheelchairs are too difficult to reach with hooks. For more information, visit Qstraint.com We began with a simple question: How can wheelchair passengers be safely secured in vehicles? The question was answered by a team of specialists from Queens University in Ontario, Canada (hence the crown in our corporate logo).
