SYSTEM DEFINITIONS
1
2
3
4
5
6
1
2
3
4
5
6
1. Power Source Connector (12 PWR)
2. Backrest Connector (6 BKRST)
3. Auxiliary Alarm (10 AUX ALM)
4. Park Brake, Ignition and Driver Interface Connector (5 DRIVER CNTRL)
• Driver Interface (Master Switch and Occupant Switch)
5. Optional Occupant Interface Connector (9 ATTND CNTRL)
6. Occupant Interface Connector (7 USER CNTRL)
