WHEELCHAIR INTERFACE BRACKET Q04BR001
QLK-150 INSTRUCTIONS FOR USE ON:
MANUAL WHEELCHAIRS WITH 1" TUBE FRAME DIAMETER,
AND LOWER FRAME RAIL HIGHER THAN 6" FROM THE GROUND
• This is a comprehensive step-by-step instruction guide on how to install the QLK-150 Q04BR001 Wheelchair Bracket.
• Make sure to read, understand and follow all these instructions.
• To address any questions contact the nearest Q'STRAINT® office.
• For installation of the QLK Docking system, please refer to the separate Installation Instructions and the Use and Care Manual.
•
Q'STRAINT recommends that a Q'STRAINT tested bracket,one designed and tested for use with a specific
transportable wheelchair should alway be used, where possible. A list of compliant wheelchair brackets can be
found on the Q'STRAINT website.
•
The Q04BR0001 is an universal bracket that may be act as an interface between a manual wheelchair and the
QLK-150 Docking system.
•
This bracket has not been tested with any specific wheelchair model and its suitability to enable a wheelchair to
be used as a seat in a motor vehicle, has not been assessed by Q'STRAINT and remains the responsibility of the
installer.
•
This bracket may not be suitable for all manual wheelchairs, and any modification or alterations remains the
responsibility of the installer.
•
This is a comprehensive step by step instruction guide on how to install the QLK-150 Q04BR001 Wheelchair
Bracket.
•
Make sure to read, understand and follow these instructions.
•
Each wheelchair should be test driven after figment of the bracket to ensure it is functioning correctly.
•
To address any questions contact the nearest Q'STRAINT office.
•
For installation of the QLK docking system, please refer to the separate installation Instructions and the Use and
Care Manual .
READ ALL INSTRUCTIONS PRIOR TO INSTALLATION
IMPORTANT SAFEGUARDS AND WARNINGS
SAVE THESE INSTRUCTIONS
