Transition Networks
DC 54V Input:
Device Status Device Interface
Non-loading None
PoE Standby 1G TP Port x8
Mode 1G SFP Port x2
PoE Full loading 1G TP Port x8
after 60 minutes 1G SFP Port x2
Non- PoE Standby 1G TP Port x8
Mode 1G SFP Port x2
Non-PoE Full
1G TP Port x8
loading after 60
1G SFP Port x2
minutes

About This Manual

This manual describes how to install, configure, and troubleshoot the SM8TAT2SA-DC switch, including how to:
•
Install the switch.
•
Check the switch status by reading the LED behavior.
•
Reset the switch or restore the switch to factory defaults.
•
Initially configure the switch.
•
Troubleshoot switch installation.

Related Manuals

SM8TAT2SA-DC Quick Start Guide (33813)
SM8TAT2SA-DC Install Guide (33814, this manual)
SM8TAT2SA-DC Web User Guide (33717)
SM8TAT2SA-DC CLI Reference (33718)
Release Notes (version specific)

For More Information

For Transition Networks Drivers, Firmware, etc. go to the
For Manuals, Brochures, Data Sheets, Specifications, etc. go to the
Note that this manual provides links to third party web sites for which Transition Networks is not responsible.
33814 Rev. A
DC Current
Consumption
(A)
0.11
2.58
2.59
0.17
0.17
Product Support
https://www.transition.com
SM8TAT2SA-DC Install Guide
DC Power
DC Voltage
Consumption
(V)
(W)
54 5.94
54 139.32
54 139.86
54 9.18
54 9.18
webpage (logon required).
Support Library (no logon required).
BTU/Hr.
20.26
475.08
476.92
31.30
31.30
Page 11 of 43
