Power Consumption
DC power consumption measured after 60 minutes under full loading with wire speed forwarding.
DC 48V Input:
Device Status Device Interface
Non-loading None
PoE Standby 1G TP Port x8
Mode 1G SFP Port x2
PoE Full loading 1G TP Port x8
after 60 minutes 1G SFP Port x2
Non- PoE Standby 1G TP Port x8
Mode 1G SFP Port x2
Non-PoE Full
1G TP Port x8
loading after 60
1G SFP Port x2
minutes
DC 52V Input:
Device Status Device Interface
Non-loading None
PoE Standby 1G TP Port x8
Mode 1G SFP Port x2
PoE Full loading 1G TP Port x8
after 60 minutes 1G SFP Port x2
Non- PoE Standby 1G TP Port x8
Mode 1G SFP Port x2
Non-PoE Full
1G TP Port x8
loading after 60
1G SFP Port x2
minutes
33814 Rev. A
DC Current
Consumption
(A)
0.11
2.88
2.88
0.17
0.18
DC Current
Consumption
(A)
0.11
2.66
2.66
0.17
0.17
https://www.transition.com
SM8TAT2SA-DC Install Guide
DC Power
DC Voltage
Consumption
(V)
(W)
48 5.28
48 138.24
48 138.24
48 8.16
48 8.64
DC Power
DC Voltage
Consumption
(V)
(W)
52 5.72
52 138.32
52 138.32
52 8.84
52 8.84
BTU/Hr.
18.00
471.40
471.40
27.83
29.46
BTU/Hr.
19.51
471.67
471.67
30.14
30.14
