Fluke Calibration 8588A Remote Programmer's Manual page 58

8588A/8558A
Remote Programmer's Manual
ARM[:SEQuence]:LAYer2
ARM[:SEQuence]:LAYer1
(The two ARM layers have identical commands)
:COUNt <nrf>
:COUNt?
:COUPling DC|AC
:COUPling?
:DELay:AUTO <boolean>
:DELAY:AUTO?
:DELay <nrf>
:DELay?
:ECOunt <nrf>
:ECOunt?
:EXTernal
POSitive|NEGative
[,TTL|BIPolar]
:EXTernal?
:FILTer <boolean>
:FILTer?
:IMMediate
:LEVel <nrf>
54
Keyword Description
Specifies the number of passes through layer and subordinate
layers before control flows up to the superior layer. Default = 1,
Max = 10000000
Returns the Count setting
Sets the coupling used with :SOURce:INTernal. See also :LEVel
and :SLOPe. Default = AC
Returns the coupling setting
When ON, the time delay between source event detection and
flow passing to the subordinate layer is determined
automatically (the DMM sets an appropriate delay needed for
settling after a configuration change). Default = ON
Returns the auto delay setting, 1 = ON, 0 = OFF
Set the time delay between source event detection and flow
passing to the subordinate layer.
Returns the delay setting in seconds
numeric is an integer value to specify how many ARM events
must be recognised before DELay is started on the downwards
transit through the layer. ECOunt provides ARM event division.
Default = 1, Max = 10000000
Returns the Ecount setting
Sets the polarity of the External trigger edge and optionally
signal type to TTL or Bipolar. Default = Negative, TTL
Returns the external edge polarity and edge type settings
Turns the filter in the event detector path ON or OFF. The filter
affects both the signal and event detector paths. Default = OFF
Returns the filter state
Modifies event detection behaviour. If the system is waiting for
an event in this layer, this one-time command bypasses event
detection ECOUNT and DELay causing immediate exit from the
layer on the downward path. If not waiting at the event detector
the command is ignored and error -221 issued.
Sets the percentage of range at which arming occurs when
Source is INTernal. Default = 0%, Min -200 %, Max = 200 %
