8588A/8558A
Remote Programmer's Manual
:RANGe:AUTO[:STATe] ?
:RANGe <nrf>|MIN|MAX|DEF
:RANGe? [MIN|MAX|DEF]
:RESolution <nrf>|MIN|MAX|DEF
:RESolution? [MIN|MAX|DEF]
[:SENSe]:DIGitize
:APERture <nrf>|MIN|MAX|DEF
:APERture? [MIN|MAX|DEF]
:CURRent:COUPling AC|DC
:CURRent:COUPling?
:CURRent:RANGe
<range>|MIN|MAX|DEF
:CURRent:RANGe? [MIN|MAX|DEF]
:FILTer OFF|100Khz|3MHZ
:FILTer?
:VOLTage:COUPling:SIGNal
AC1M|AC10M|DC1M|DC10M|DCAuto
:VOLTage:COUPling:SIGNal?
:VOLTage:RANGe
<range>|MIN|MAX|DEF
:VOLTage:RANGe? [MIN|MAX|DEF]
26
Table 6. Command Summary (cont.)
Keyword Description
Returns 1 for Auto range ON, 0 for auto range OFF
Set maximum expected value or min, max or default range
Returns the selected range or, if specified, the minimum,
maximum or default range
Set maximum expected value or min, max or default resolution;
for example, range is 1 A, Resolution <nrf>. = 0.0001 (100 µA),
the measurement is returned with a resolution of +1.000E-4
Returns the selected resolution, or if specified, the minimum,
maximum or default range
Sets the ADC aperture value in seconds or to the MIN, MAX, or
default setting
Returns the aperture setting or, if specified, the MIN, MAX, or
Default settings in seconds
Sets the current signal coupling path to ac or dc
Returns the current signal coupling path
Sets the maximum expected current value or the MIN, MAX, or
Default range
Returns the current range set
Sets the digitise Filter bandwidth to OFF, 100 kHz, or 3 MHz
(default is 3 MHz)
Return the Digitize low pass filter setting
Set the voltage path coupling and input impedance
AC1M = AC Coupling, 1 MΩ input impedance
AC10M = AC Coupling, 10 MΩ input impedance
DC1M = DC Coupling, 1 MΩ input impedance
DC10M = DC Coupling, 10 MΩ input impedance
DCAuto = DC Coupling, maximum available input impedance
(>1 TΩ for ranges < 100 V; 10 MΩ, for the 100 V, and 1000 V
ranges)
Return the voltage path coupling and input impedance setting
Sets the maximum expected voltage value or the MIN, MAX, or
Default range
Returns the voltage range set
