8588A/8558A
Remote Programmer's Manual
:COUNter:GATE <range>|MIN|MAX|DEF
:COUNter:GATE? [MIN|MAX|DEF]
:COUPling:SIGNal
AC1M|AC10m|DC1M|DC10m|DCAuto
:COUPling:SIGNal?
:FILTer <nrf>|MIN|MAX|DEF
:FILTer? [MIN|MAX|DEF]
:RANGe:AUTO[:STATe] <boolean>
:RANGe:AUTO[:STATe]?
:RANGe <nrf>|MIN|MAX|DEF
:RANGe? [MIN|MAX|DEF]
:RESolution <nrf>|MIN|MAX|DEF
:RESolution? [MIN|MAX|DEF]
:SECondary
OFF|FREQuency|PERiod|PTP
|PPEak|NPEak|CFACtor
34
Table 6. Command Summary (cont.)
Keyword Description
Sets the secondary frequency counter measurement gate
Returns the secondary frequency counter measurement gate
Sets the coupling and input impedance of the signal path
Returns the signal path coupling and bandwidth setting
Sets the input filter to value or to the minimum, maximum or
default setting. The filter setting range is 0.1 Hz to 1 kHz, the
discrete settings are: 0.1 Hz, 1 Hz, 10 Hz, 40 Hz, 100 Hz, 1 kHz.
The discrete setting closest to <nrf> will be selected.
Returns the Filter setting, or if specified, the MIN, MAX, or
Default setting
Turns Auto range ON or OFF
Returns 1 for Auto range ON, 0 for auto range OFF
Set maximum expected value or MIN, MAX, or Default range
Returns the selected range or, or if specified, the MIN, MAX, or
Default range
Set maximum expected value or min, max or default resolution;
for example, range is 1 V, Resolution <nrf>. = 0.0001 (100 µV),
the measurement is returned with a resolution of +1.000E-4
Returns the selected resolution, or if specified, the MIN, MAX, or
Default range
Sets the secondary reading type
OFF = Secondary reading is not shown
FREQuency = Secondary reading is frequency
PERiod = Secondary reading is period
PTP = Secondary reading is peak-to-peak
PPEak = Secondary reading is positive peak
NPEak = Secondary reading is negative peak
CFACtor = Secondary reading is the crest factor
