Fluke Calibration 8588A Remote Programmer's Manual page 43

Keyword
:SHUNt:LIST?
SHUNt:MODify <list#>,< list>
:SHUNt:PICK <list#>
:SHUNt:PICK?
:SHUNt:REMove <list#>
SHUNt:SORT MCURrent|ASSet|SERial
SHUNt:SORT?
Note(1): External shunts data is common between SENSe:XCURrent:AC and SENSe:XCURrent:DC
[:SENSe]:XCURrent:DC
:APERture <nrf>|MIN|MAX|DEF
:APERture? [MIN|MAX|DEF]
:APERture:MODE AUTO|FAST|MANual
:APERture:MODE?
:NPLC <nrf>MIN|MAX|DEF
:NPLC? [MIN|MAX|DEF]
:RANGe:AUTO[:STATe]<boolean>
:RANGe:AUTO[:STATe]?
:RANGe <nrf>|MIN|MAX|DEF
Table 6. Command Summary (cont.)
Returns a comma-separated enumerated list of
shunts as {List#, Asset#, Manufacturer, Model,
Serial#, Resistance, Max Current, Power Ref Level,
Power Coefficient}
Note1: The first four items are quoted strings, the
remaining item are NR3 format values.
Note2: If the optional <list#> is supplied that record is
returned, otherwise the active shunt record is
returned.
Note3: Index '0' is the 'Basic' shunt slot, and is always
available.
<list> See notes to SHUNt?
selects shunt by enumerated list number
Returns selected shunt number
Remove the shunt at # in the list
Sort shunt list in either 'maximum current', 'asset
number' or 'serial number' order
Returns the sort order (MCUR|ASS|SER)
Sets the ADC aperture value in seconds or to the
MIN, MAX, or Default setting
Returns the aperture setting or the MIN, MAX, or
Default settings in seconds
Sets the aperture mode
Returns the aperture mode
Sets the ADC aperture in number of power line cycles
or to the MIN, MAX, or Default plc setting
Returns the ADC aperture in number of power line
cycles or to the MIN, MAX, or Default plc setting
Turns Auto range ON or OFF
Returns 1 for Auto range ON, 0 for auto range OFF
Set maximum expected value or MIN, MAX, or Default
range
Reference Multimeter and 8 ½ Digit Multimeter
Description
SCPI Commands Reference
39
