CONNECTION OF THE COMbIVERT F5-AIC
Terminal
Name
block
L1, L2, L3
U, V, W
X1A
+PA, PB
+PA, –
T1, T2
X1D
K1, K2
X1A
PE,
Figure 7: Terminal blocks housing P
38
Housing P
Function
3-phase mains connection
AIC mains connection
Connection for braking resistor
Connection for DC-bus connection
Connection for temperature sensor (only master)
Monitoring of the braking transistor (GTR7)
(only water-cooled devices)
Connection for protective earth
Terminal width
max. 42,5mm
Terminal
13
9
13
