Assembly & start up
This chapter has the following sections:

• What's in the box

• To assemble the EXPLORER 6075LX
• Power on and auto-pointing
• To disassemble and pack the antenna
3.1 What's in the box
3.1.1 To unpack
Two transit cases contain the EXPLORER 6075LX:
• Case with RF assembly and reflector petals (left)
• Case with Base Unit and antenna positioner (right)
CAUTION!
After mounting the feed horn on the RF assembly, do not carry the RF
assembly by the feed horn. The subreflector can be easily damaged.
98-165591-B

Figure 3-1: Transit cases

Be careful when handling the feed horn and the RF assembly.
