Chapter 3 Assembly & Start Up; What's In The Box; To Unpack - COBHAM EXPLORER 3075GX User & Installation Manual

Manual-deploy fly-away system for inmarsat gx

Hide thumbs Also See for EXPLORER 3075GX:

Table of Contents

Assembly & start up

This chapter has the following sections:

• To assemble the EXPLORER 3075GX

• Power on and manual pointing

• To disassemble and pack the antenna

3.1

What's in the box

3.1.1

Two transit cases contain the EXPLORER 3075GX antenna system:

• Case with RF assembly and electronics enclosure (left)

• Case with tripod, antenna panels and cables (right)

Do not grab the RF assembly by the

Note

feed horn. The RF feed's subreflector

can be easily damaged.

Hold the RF feed as shown in the

picture.

98-144390-C

Figure 3-1: 2 transit cases

Chapter 3

3-1
