Under ADMINISTRATION > User permissions you can change the settings so that no
password is required to access the guest part of the web interface. The administrator
password however, is mandatory.
For details, see:
• To change the guest login password (User administration) on page 4-18
• User permissions (for guest user) on page 4-18
• Administrator access to the web interface (user name, password) on page 4-17
2.2.6
Local IP ports and WLAN
The Base Unit has four local IP connectors (type RJ45) for connecting a PC/laptop or similar.
• Service port on the left-hand side (Port 1) for system control via the web interface.
Important
• Two connectors (Port 2 and Port 3) for user PCs for Internet etc., configured by the GX
modem.
• Management port (Port 4), e.g. for system control from a PC on a corporate network.
Port 4 is configured as DHCP client by default.
The EXPLORER 6075LX has a WLAN module. Access to one of the Local IP ports using
WLAN must be set up in the web interface, see To configure the LAN network on page 4-6.
2.2.7
Power supply
The internal power supply supplies power to the Base Unit, LNB and BUC. Power input is
specified as 24 VDC to 48 VDC nominal, for more details see Technical specifications on
page A-1.
2.3
Part numbers
2.3.1
System part numbers
The EXPLORER 6075LX system has the following part number and consists of the following
units:
Part number
406616C-50114 EXPLORER 6075LX
98-165591-B
Port 1 is configured as DHCP server by default. If you are connecting a
corporate network, use Port 4 instead.
Description
Stabilized Auto-Acquire
Antenna System for
Inmarsat Global Xpress
Chapter 2: Introduction
Base Unit
RF-package
EXPLORER 6000LX
EXPLORER LX RFP
Base Unit
and 75 cm petals
Part numbers
Modem
GX modem
built into the
Base Unit
2-7
