• <Modem TX> = [m,M], M (valid TX signal on modem) or m (no valid TX signal on
modem)
• <ODU TX> = [a,A] A (valid TX signal on antenna) or a (no valid TX signal on antenna)
• <TX pol> = [-, X, C] (TX polarization of currently active satellite profile: X (X-pol),
C (Co-pol) or - (unknown)).
After 1 hour the display is dimmed to lowest intensity. Press any key to light up the display.
4.9.2 Brightness of the display
To adjust the brightness do the following:
1. Press and hold OK for a short moment until BRIGHTNESS XXX% is displayed (XXX is
the current brightness value).
2. Hold OK + press  to brighten or  to darken display.
3. Release OK to leave the brightness menu.
4.9.3 Navigating the menus
Use the keypad to navigate the menus.
• Press OK or  to select a menu item.
• Use the arrow keys  and  to go through the menu items or enter a
number, digit by digit.
• Use the arrow keys  and  to go through the settings and move
from one digit to the next.
• Press OK to select a setting.
• Press  to move one level up. If applicable, confirm to store the new setting by pressing
OK.
Menu shortcuts
• Deploy: Press and hold  to deploy the antenna after it has been stowed.
• Stow: Press and hold  to Stow the antenna
• Administrator access: Press and hold  for 5 seconds to get temporary administrator
access for 1 hour or until next restart. For details, see New installation or forgotten
password on page 4-4.
