Event ID
Severity
08073-0
WARNING Slave connection The system is configured as a dual antenna master, but no
08074-0
WARNING Master
08075-0
WARNING Rx cable
08076-0
WARNING Dual mode
08078-0
WARNING VMU TX
08079-0
WARNING ACU Fan
0807A-0
WARNING Automatic
0807B-0
WARNING OTC required
0807C-0
ERROR
98-165591-B
Description
dual antenna slave is connected to it. Either disable the
dual antenna master in the web interface or configure a
another system as a dual antenna slave.
The system is configured as a dual antenna slave, but it was
connection
not possible to connect to the dual antenna master. Check
that the IP address entered in the modem profile is correct
and check that the master and slave systems are physically
connected as described in the manual.
The calibration of the ACU-antenna cable failed. The cable
calibration
could be defective, too long, of too poor quality, not
properly connected, or the VIM or ACU hardware could be
defective.
The system is configured as a dual antenna system, but the
configuration
system setup is invalid. The dual mode function may not
work properly or performance could be degraded. Info
code: xxxxxxx1 = Antenna types are different, they must
be identical xxxxxxx2 = Master or Slave hardware does not
support dual mode operation. xxxxxxx3 = Software version
on master and slave are different, they must be identical.
The satellite modem did not provide a Tx frequency, or it is
frequency invalid
invalid. A default Tx frequency is assumed, but this may
degrade Tx performance. To remove this warning re-
configure the modem to provide the correct Tx frequency.
Internal fan is malfunctioning.
Automatic azimuth calibration mode is enabled. The
azimuth
system tries to perform an azimuth calibration using the
calibration
target satellite whenever satellite data is received from the
pending
modem. After successful calibration the feature is
automatically disabled and the system returns to normal
operation. WARNING: If a system has not completed
azimuth calibration after the installation, the blocking
zones may appear to be at wrong angles.
BUC calibration is outdated. Rerun it from the Core Module
(Calibration
by using the One Touch Commissioning in the web
outdated)
interface.
System
Invalid ACU / antenna combination.
configuration
Appendix B: System messages
Explanation
List of events
B-3
