COBHAM EXPLORER 6075LX User & Installation Manual page 90

Event ID Severity
0A021-0 ERROR
0A022-0 ERROR
0A023-0 ERROR
0A025-0 ERROR
0A028-0 ERROR
0A029-0 ERROR
0A02B-0 ERROR
0A02D-0 ERROR
0A034-0 WARNING ACU
0A035-0 WARNING ISM data valid
0A036-0 WARNING ISM data range
0A037-0 WARNING GNSS
0A038-0 WARNING GNSS data
0A039-0 WARNING GNSS device
0A03A-0 WARNING GNSS device
98-165591-B
Description
Azi axis Azimuth axis zero reference not found. Check belt and zero
calibration reference module. Info: 0x00000001: Timeout (operation
did not complete in time)
mechanical problem
found
Xel axis Cross-elevation axis zero reference or end stops not found at
calibration expected locations. Check belt, zero reference module, and
end stops. Info: See 0A021-0.
Ele axis Elevation axis zero reference or end stops not found at
calibration expected locations. Check belt, zero reference module, and
end stops. Info: See 0A021-0.
Antenna One or more errors occurred during antenna start-up Info:
calibration 0x00000001: Timeout (calibration did not complete in time)
0x00000010: Azimuth axis
axis
Polarisation axis
Demodulator The second receiver demodulator cannot be initialised and
load loaded correctly.
XIM PLL lock The PLL on the VIM does not lock.
ABS software The ABS software version in the antenna is too old to match
version the hardware requirements. Upload new software via the
web interface.
BUC reference The BUC reference switches do not work. Check PCM-VIM
switch cable and replace cable, VIM or PCM.
The communication link between ACU and antenna is not
communication working.
Sensor measurements from the ISM are invalid. This
indicates a malfunctioning ISM.
Sensor measurements from the ISM are out of range.
Lost connection to the GNSS device.
communication
Received information from the GNSS device which is out of
range range.
Local GNSS device warning.
warning
Local GNSS device error.
error
Appendix B: System messages
Explanation
0x00000010: Encoder or
0x00000020: Zero reference not
0x00000040: End stop not found.
0x00000020: Cross-elevation
0x00000040: Elevation axis
List of events
0x00000080:
B-9
