Event ID Severity
0A03B-0 ERROR
0A03C-0 ERROR
0A03D-0 ERROR
0A03E-0 ERROR
0A03F-0 WARNING AMB timing
0A040-0 WARNING VIM cable attn
0A043-0 WARNING LNB voltage low The voltage for the LNB is too low probably caused by a
0A044-0 WARNING LNB voltage
0A047-0 ERROR
0A048-0 WARNING VIM tuner lock
0A049-0 WARNING Azi encoder slip A slip of the azimuth encoder has been detected. If this
0A04A-0 WARNING Xel encoder slip A slip of the cross-elevation encoder has been detected. If
0A04B-0 WARNING Ele encoder slip A slip of the elevation encoder has been detected. If this
0A04D-0 WARNING GNSS position
0A04E-0 WARNING GNSS velocity
0A04F-0 WARNING Heading data
98-165591-B
Description
Azi DDM The azimuth motor control has detected one of the following
shutdown situations: Extreme temperature, voltage, current or velocity.
The motor was then shut down. This is usually a temporary
situation and is probably fixed by a restart of the system.
Xel DDM As Azi DDM/DMD/FDM shutdown but detected by the cross-
shutdown elevation motor control.
Ele DDM As Azi DDM/DMD/FDM shutdown but detected by the
shutdown elevation motor control.
PMM shutdown As Azi DDM/DMD/FDM shutdown but detected by the
polarisation motor control.
This indicates a busy situation. It may occur during
installation procedures. No user interaction is required unless
it occurs repeatedly.
The output power cannot be controlled correctly. Check the
Tx chain.
malfunctioning VIM or LNB.
The voltage for the LNB is too high probably caused by a
high malfunctioning VIM.
VIM PLL lock The PLL of the VIM is out of lock. Check the 10 MHz
reference signal.
The PLL of the second receiver (DVB) is out of lock. Check the
10 MHz reference signal.
event is not resolved by itself after some time, check the belt
and encoder of the azimuth axis.
this event is not resolved by itself after some time, check the
belt and encoder of the cross-elevation axis.
event is not resolved by itself after some time, check the belt
and encoder of the elevation axis.
No position available from the GNSS device or position too
old.
No velocity available from the GNSS device.
Heading information is missing in the antenna.
