Assembly & start up
This chapter has the following sections:

• What's in the box

• To assemble the EXPLORER 5075GX
• Start up with auto-acquisition
• To stow the antenna
• To disassemble and pack the antenna
What's in the box
3.1
3.1.1

To unpack

The EXPLORER 5075GX antenna system is packaged into two transit cases.
• Case 1 - RF assembly and reflector
• Case 2 - Electronics enclosure and antenna positioner
Take care when handling the feed assembly. Do not grab the assembly by the feed
Note
horn. The feed's subreflector can be easily damaged.
98-143492-B
Figure 3-1: 2 transit cases
Chapter 3
3-1
