Figure 5-4: Web interface: SETTINGS, VSAT modem profile – supported modems
2. Fill in a modem profile name of your own choice.
3. Select the Generic modem (for troubleshooting) from the drop down list.
4. Click Apply to add the new profile to the list of VSAT modem profiles or to accept the
edits.
For a generic modem you enter all parameters in the satellite profile.
5.1.5 Manual One Touch Commissioning (OTC)
When the modem starts up for the first time it will automatically register with the BUC and
perform P1dB compression on multiple frequencies and then register with the Inmarsat
network. During the P1dB compression the antenna will point away from the satellite and
transmit on 29 GHz to 30 GHz. The EXPLORER 6075LX will show BUC Calibration on the
DASHBOARD and the Base Unit display. This may take up to 10 minutes.
If you want to make a manual OTC for the modem, do as follows:
98-165591-B

Figure 5-5: Satellite profile with generic GX modem

WARNING! For your safety: Active RF transmission may occur during an
OTC procedure. Software updates may also occur, even though the system is
in receive-only mode during such auto-updates.
Chapter 5: Service
General support
5-5
