To stow the antenna manually
See To stow the antenna manually on page 5-18.
3.4
To disassemble and pack the antenna
1. Press the ON/OFF button on the unit to power it off.
2. Remove all cables.
3. Dismantle the four reflector petals.
4. Unscrew the feed horn from the Rf assembly and place it carefully in the dedicated
cutout in the transport case for the RF assembly.
5. Loosen the thumb screws and remove the RF assembly from the antenna positioner.
6. Put all parts into the dedicated cutouts in the two transport cases.
98-165591-B
WARNING! The Base Unit may get very hot in sunny and hot weather
conditions. Do not move the unit! Touching the hot unit may cause bodily
harm. Wait until the unit has cooled down.
CAUTION!
Take care when handling the feed horn. The feed's
subreflector can be easily damaged.
Chapter 3: Assembly & start up
To disassemble and pack the antenna
3-13
