5.1.4 Satellite profiles and modem profiles
5 satellite profiles with the GX Modem are already set up at the factory (1 for each satellite
and one Auto). You may add a satellite profile with the generic modem for troubleshooting
purposes.
Satellite profiles – New entry and Edit

Figure 5-3: Web interface: SETTINGS - list of satellite profiles (example)

Each satellite profile has one assigned modem profile. To add or edit a satellite profile, do as
follows:
1. Go to SETTINGS > Satellite profiles and click Edit or New entry.
2. Enter or edit the Satellite profile name.
3. Select a modem profile. The page automatically displays the parameters available for the
selected VSAT modem profile. For instructions how to add a modem profile see the
following sections.
4. Enter the data for the satellite, if any.
5. Click Apply to save the settings for the satellite profile.
Modem profiles
On the page Modem profiles you create, edit or delete VSAT modem profiles. The VSAT
modem profile GX Modem is already set up at the factory. It is useful for troubleshooting to
create a VSAT modem profile with the Generic modem.
Modem profile – New entry and Edit
To add or edit a VSAT modem profile, do as follows:
1. Go to SETTINGS > Modem profiles and click New entry or Edit. The supported
VSAT modem profiles are listed in the drop-down list Modem.
