Selecting Images

The Images are shown in a tree structure on the top left panel.
The tree structure organizes the images by:
Set (line on the Test Sequence window)
Cycle (iteration of a given Set)
Phase (Preload/Stretch/Hold/Recovery/Rest of each Cycle)
Image (the one or more individual images from each Phase)
You can select which images to include in a playback set in
one of several ways:
•
hold down the shift key and click on individual images
•
select entire sets, cycles, or phases (will playback all
contained images)
•
select images which have data associated with a
particular tracking set

Image Playback Options

The controls on the left of the screen are broken into 2 sections:
Playback and Tracking.
The playback buttons allow the user to review the images taken during
a test.
Next/Prev Display next or previous image (as dictated by "Play Every" parameter).
Play/Stop Start and stop the playback.
Prev/Next Cycle Jumps to a corresponding image and phase in the next or previous cycle. Useful when reviewing
sets that have multiple cycles.
Loop Sequences can be played continuously in a loop or only once.
Playback Rate +/- changes the speed of the playback. A playback rate can also be manually entered in the
display box.
Play Every Allows the users to skip some frames to expedite playback.
