Installation of
Electrical Power
and Data
1.
Skip to Power and Data assembly instructions:
NOTE: Make sure to install the felt pad with the perferations in the felt
liner aligned /overlapping with the cutouts in the connect zone power
trough before installing any power &/or data into the desk understructure.
939549924 c:scape Modular Desk Power and Data
939549925 c:scape Desk Hardwire Power
939549926 c:scape Desk Connect Zone Power Strip
939549927 c:scape Receptacles - Desk, Base or Storage
CUTOUT
CUTOUT
Page 10 of 21
939505503 Rev A
