Steelcase c:scape Manual

Steelcase c:scape Manual

Low storage counterweight packages
Hide thumbs Also See for c:scape:
1
2
3
4

Advertisement

Quick Links

Download this manual
If you have a problem, question, or request, call
your local dealer, or Steelcase Line 1 at
888.STEELCASE (888.783.3522)
for immediate action by people who want to help you.
(Outside the U.S.A., Canada, Mexico, Puerto Rico,
and the U.S. Virgin Islands, call: 1.616.247.2500)
Or visit our website: www.steelcase.com
©
2009 Steelcase Inc.
Grand Rapids, MI 49501
U.S.A.
Printed in U.S.A.
™
c:scape
Low Storage Counterweight Packages
Counterweight
Packages
3
4
4
3
Table of Contents
Topic
Removing a Drawer
Installing Counterweight Packages
Re-Installing the Drawer
Case Width
Style No.
30"
CQLC1
36"
CQLC2
42"
CQLC2
48"
CQLC1
Page
2
3
4
#2 SQUARE
OR QUADREX
#2 SQUARE
OR QUADREX
DRIVE BIT
Page 1 of 4
939500370 Rev D
