Steelcase c:scape Low Storage Series Assembly Instructions Manual

1 High x 30", 36" or 42" Wide
Open Drawer
1 High x 48" Wide
1-1/2 High x 30", 36" or 42" Wide
Open Above/ Open Above/
Open Below Drawer Below Inline Slider Below
Drawer Above/
Drawer Above/
Drawer Below Inline Slider Below
Open Below
If you have a problem, question, or request, call
your local dealer, or Steelcase Line 1 at
888.STEELCASE (888.783.3522)
for immediate action by people who want to help you.
(Outside the U.S.A., Canada, Mexico, Puerto Rico,
and the U.S. Virgin Islands, call: 1.616.247.2500)
Or visit our website: www.steelcase.com
©
2009 Steelcase Inc.
Grand Rapids, MI 49501
U.S.A.
Printed in U.S.A.
Furniture should be installed in sequence shown below.
Inline Slider
1
BEAM
1-1/2 High x 48" Wide
Open Above/
Drawer Above/
1 High x 60" or 72" Wide
1-1/2 High x 60" or 72" Wide
c:scape
2 3 4
MID STORAGE DESKING POWER
THIS INSTALLATION SEQUENCE IS HERE.
Table of Contents
Topic
Moving, Loading, Unloading
and Storing
Removal of Plastic Lock Plug
and Installation of Lock Cylinder
Front Removal of Lock Cylinder
Removing a Drawer
Installation of a Drawer Suspension
Installation of the Glides and
Leveling the Case
Checking the Interlock Function
Ganging Low Storage Cases Together:
Side-to-Side
Ganging Low Storage Cases Together:
Back-to-Back
Dividers, Rails and Adjustable Bars
Installation of Box Drawer Liner
Installation of Cushion Top
Assembly of the Storage to Beam
Tether Brackets
™ Low Storage Products
5 6
LOW STORAGE PRIVACY
#2 SQUARE
OR QUADREX
Page
2
3
4
5
6
7
8
9
10
11
12
12
13-15
939500368 Rev K
#2 SQUARE
OR QUADREX
DRIVE BIT
Page 1 of 15
