Steelcase c:scape Quick Manual

Desk Receptacle
Attach any chosen receptacle into the desk power block, by
pushing in (a) then sliding over into the mating contacts (b).
The receptacle will lock into place. Attach decorative
faceplate around the receptacle (c).
NOTE: This equipment has been tested and
found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable
protection against harmful interface when the
equipment is operated in a commercial environment.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is
likely to cause harmful interference in which case
the user will be required to correct the interference
at his own expense.
If you have a problem, question, or request, call
your local dealer, or Steelcase Line 1 at
888.STEELCASE (888.783.3522)
for immediate action by people who want to help you.
(Outside the U.S.A., Canada, Mexico, Puerto Rico,
and the U.S. Virgin Islands, call: 1.616.247.2500)
Or visit our website: www.steelcase.com
© 2014 Steelcase Inc.
Grand Rapids, MI 49501
U.S.A.
Printed in U.S.A.
FLEX RECEPTACLE
USB RECEPTACLE
OR
b
c:scape ™ Receptacles - Desk, Base or Storage
Furniture should be installed in sequence shown below.
1 2
BEAM POWER
NOTE: Unused modular electrical
connector openings are not
required to be capped.
RECEPTACLE
OR
a
3 4
MID STORAGE DESKING
THIS INSTALLATION SEQUENCE IS HERE.
c
DECORATIVE
FACEPLATE
5 6
LOW STORAGE PRIVACY
Page 1 of 2
939549927 Rev F
