Textron LF-128 Safety & Operation Manual

Fairway mower kubota d1105-eb diesel engine 2wd model 67818 4wd model 67819
Hide thumbs
Table of Contents

Advertisement

Quick Links

BOB-CAT • BUNTON • CUSHMAN • JACOBSEN • RANSOMES • RYAN
WARNING: If incorrectly used this machine can cause severe injury. Those who use
!
and maintain this machine should be trained in its proper use, warned of its dangers
and should read the entire manual before attempting to set up, operate, adjust or ser-
vice the machine.
Litho in U.S.A. 1199
Safety &
Operation
Manual
Fairway Mower
Kubota D1105-EB

Diesel Engine

2WD Model 67818
4WD Model 67819
TURF CARE AND SPECIALTY PRODUCTS
™
LF-128
Part No. 2811252

Advertisement

Table of Contents
loading

Related Manuals for Textron LF-128

Summary of Contents for Textron LF-128

  • Page 1: Diesel Engine

    Safety & Operation Manual ™ LF-128 Fairway Mower Kubota D1105-EB Diesel Engine 2WD Model 67818 4WD Model 67819 BOB-CAT • BUNTON • CUSHMAN • JACOBSEN • RANSOMES • RYAN WARNING: If incorrectly used this machine can cause severe injury. Those who use...

  • Page 2: Table Of Contents

    “All rights reserved, including the right to reproduce this book or portions thereof in any form”. All information in this publication is based on information available at time of approval for printing. Textron Turf Care And Specialty Products reserves the right to make changes at any time without notice and without incurring any obligation.

  • Page 3: Safety

    SAFETY SAFETY OPERATING SAFETY ______________________________________________________ WARNING EQUIPMENT OPERATED IMPROPERLY OR BY UNTRAINED PERSONNEL CAN BE DANGEROUS. Familiarize yourself with the location and proper use of all controls. Inexperienced operator’s should receive instruction from someone familiar with the equipment before being allowed to operate the machine. Safety is dependent upon the awareness, concern and Never disconnect or bypass any switch.

  • Page 4: Important Safety Notes

    Adjustments and maintenance should always be performed by a qualified technician. If additional information or service is needed, contact your Authorized Textron Turf Care And Specialty Products Dealer who is kept informed of the latest methods to service this equipment and can provide prompt and efficient service. Use of other...

  • Page 5: Decals

    DECALS DECALS Familiarize yourself with the decals they are critical to the safe operation of the machine. REPLACE DAMAGED DECALS IMMEDIATELY. CAUTION DANGER To prevent injury: To install the battery: • Always connect red battery cable 1. Install battery with terminals toward frame cen- to the positive (+) post FIRST and ter.

  • Page 6: Decals

    DECALS WARNING DANGER RADIATOR IS UNDER PRESSURE. REMOVE CAP SLOWLY TO AVOID BODILY INJURY. Always keep hands and clothing far away from powered reels to prevent severe bodily injury. Reels may turn 365956 slowly with bypass valves open. Never Backlap reels with the engine running in an enclosed building WARNING BACKLAPPING PROCEDURE:...

  • Page 7: Controls

    CONTROLS CONTROLS ICONS ___________________________________________________________________ Read Manual Engine Reel Rotation Engine Throttle Start High Forward Reverse (Cut) (Backlap) Oil Level Switch Hour Meter Parking Brake Drive Engaged Disengaged Off/Test 2-WD 4-WD Wing Mowers Reels Travel Forward Reverse Glow Plugs Center Mowers Lower Raise Miscellaneous...
  • Page 8 CONTROLS Seat Adjusting Lever Air Cleaner Indicator Voltmeter Parking Brake Backlap Switch Hour Meter Lift /Lower Pedal Wing Mower Switch Temperature Gauge Mow Speed Pedal Center Mower Switch Engine Oil Light Traction Pedal - Forward Hyd. Oil Level Light W Engine Throttle Traction Pedal - Reverse Hyd.

  • Page 9: Controls

    CONTROLS CONTROLS_______________________________________________________________ A. Seat Control Pull left side lever out to adjust seat forward or backward. To adjust spring tension under seat turn adjusting knob on front of seat. B. Parking Brake Pedal / Parking Brake Lock To lock parking brake, depress brake pedal (B ) and lock latch (B ) with your heel.

  • Page 10: Control Panel

    CONTROLS CONTROL PANEL _________________________________________________________ Figure 3C L. Wing Mower Switch Q. Mower Switch Engages or disengages wing mowers. Depress front of Used to enable or disable reel switches (L and M). Lift switch for forward rotation. Depress rear of switch for toggle lever then push forward to engage.
  • Page 11 CONTROLS When an alert occurs follow the general guidelines listed in This system monitors: the chart below, and any specific actions outlined by the Hydraulic fluid level grounds superintendent or service manager. Engine oil pressure Engine Coolant Temperature Battery Voltage Alert Action 1.

  • Page 12: Daily Inspection

    OPERATION OPERATION DAILY INSPECTION________________________________________________________ Check the fuel supply, radiator coolant level, crankcase CAUTION: The daily inspection should be per- oil and air cleaner indicator. All fluids must be at the full formed only when the engine is off and all fluids are level mark with engine cold.

  • Page 13: Operating Procedures

    Only use accessories and attachments obscure vision. approved by Textron Turf Care And Specialty Products. 11. Never use your hands to clean cutting units. Use a Never direct discharge of material toward bystanders, brush to remove grass clippings from blades.

  • Page 14: Starting

    OPERATION STARTING _______________________________________________________________ IMPORTANT: Do not use starting assist fluids. Use of All warning lights should go off after engine starts. such fluids in the air intake system may be potentially Allow engine to gradually become warm before explosive or cause a “Runaway” engine condition and could operating at high RPM.

  • Page 15: To Drive / Transport

    OPERATION TO DRIVE / TRANSPORT ____________________________________________________ Read and follow all safety notes contained in this manual Place the transport bar (C) between the cylinder pivot when driving or transporting tractor. When operating in pin and the lift arm as shown. Secure bar in place with reverse look behind you to ensure you have a clear path.

  • Page 16: Towing / Trailering

    OPERATION TOWING / TRAILERING _____________________________________________________ If the tractor experiences problems and must be shut down NOTE: Do not exceed 3 MPH (5 KPH) while towing. Long and removed from the area, it should be loaded onto a trailer distance towing is not recommended for transport.

  • Page 17: 4.10 Wing Stops

    OPERATION 4.10 WING STOPS _____________________________________________________________ During normal operation, rotate the wing lift stops towards center of tractor to the mow position. Wing Mow Position mowers will only lift to a cross cut position. To transport, rotate wing lift stops away from center of tractor.
  • Page 18 NOTES NOTES...
  • Page 19 NOTES...

  • Page 20: Limited Warranty

    Limited Warranty 1. Warranty Textron Turf Care And Specialty Products (TTCSP) warrants only to the original retail purchaser (“Warrantee”) that this product shall be free from defects in material and workmanship for a period of one year from the date of the first retail purchase.
