sPEcIFIcatIon

Power supply
HdMI
Performance
and Interface
Protection
level
operating
environment
Body
properties
14
Voltage/Current
Power consumption TX: 2W RX: <2W
HDMI compliance
HDCP compliance
HDMI resolution
supported
Suports audio
formats
Maximum transfer
rate
Input and output
TMDS signal
Input and output
DDS signal
Input cable lenght
Output cable lenght
Electrostatic
protection of the
whole machine
Working
temperature
Storage temperature -10 ~70°C
Humidity (no
condensation)
Dimension
Material
Color
Weight
HDMI EXTENDER OVER CAT.5/5E/6
DC5V/1A
HDMI1.3
HDCP1.4
720x576@50Hz; 720x480@60Hz;
1280x720@60Hz;
1920x1080@60Hz;
640x480@60Hz; 800x600@60Hz;
1024x768@60Hz; 1280x800@60Hz;
1280x1024@60Hz;
1440x900@60Hz; 1680x1050@60Hz
PCM
10.2Gbps
0.5 ~ 1.5p-p (TMDS)
5Vp-p (TTL)
≤8m (AWG24)
≤8m (AWG24)
1a Contact discharge level 3
1b Air discharge level 3
Implementation of the standard
IEC61000-4-2
0°C ~ 60°C
0 ~ 90%
69.57 (L) x 58.80 (W) x 16.10 (H) mm
Aluminum alloy material + crystal
panel
Black
TX : 70g RX : 70g
