Specification - Techly IDATA EXTIP-3834KV4 User Manual

EN - 6
A: 1) Please check the cable length between the TX to switch, the
switch to the RX and the connection between each level is within
the required range.
2) Click the "reset" button on the TX/RX front panel, reset and
reconnect.

SPECIFICATION

HDMI compliance
HDCP compliance
Support resolutions
Network cable
Transmission distance
IR Signal
Working temperature
Power Supply
Power consumption
Protection
Dimensions
Weight
Color
Maintenance: clean only with a dry cloth. Do not use cleaning solvents
or abrasives.
Warranty: no guarantee or liability can be accepted for any changes and
modifications of the product or damage caused due to incorrect use of this
product.
In compliance with EU Directive WEEE this product is marked with
this symbol. It means that used electrical and electronic products
should not be mixed with general household waste. There is a
separate collections system for these products in compliance with
WEEE directive, otherwise contaminative and hazardous substances can
pollute the environment.
With the CE sign, Techly
the basic European standards and directives.
WWW.TECHLY.COM
HDMI1.4
HDCP1.4
480i@60Hz, 480p@60Hz, 576i@50Hz,
576p@50Hz, 720p@50/60Hz,
1080i@50/60Hz, 1080p@50/60Hz,
4Kx2K@24/25/30Hz
UTP/STP Cat5/5e/6
Up to 120m transmission distance for
4Kx2K@30Hz Full HD over single CAT6
Supports 20-60KHz IR devices
0°C – 60°C
DC5V/2A
TX: 6W; RX: 4W
Lightning protection / Surge protection /
ESD protection
107.3 (W) x 94 (D) x 23.7 (H) mm * 2pcs
TX: 170g RX: 167g
Black
ensures that the product is conformed to
®
4KX2K HDMI
EXTENDER
