EN - 8
SPECIFICATIONS
Items
Voltage/Current
Power
Supply
Power Consumption
HDMI compliance
HDCP compliance
HDMI resolution
HDMI
Performance
And
Supports audio formats
Interface
Input and output TMDS
signal
Input and output DDC signal
Input cable length
Output cable length
Transmission
CAT6/6A/7
Distance
Protection Electrostatic protection of
Level the whole machine
Working temperature
Operating
Storage temperature
Environment
Humidity (no condensation)
Dimension
Material
Body
Treatment Process
Properties
Color
Weight
In compliance with EU Directive WEEE this product is marked with this symbol. It means that used
electrical and electronic products should not be mixed with general household waste.
There is a separate collections system for these products in compliance with WEEE directive, otherwise
contaminative and hazardous substances can pollute the environment
With the CE sign, Techly
directives.
WWW.TECHLY.COM

Specification

DC5V/1A
TX < 2.5W RX < 2.5W
HDMI 1.3
HDCP 1.4
800x600, 1024x768, 1280x720, 1280x960,
1366x768, 1440x900, 1680x1050,
1920x1080, 480i@60Hz, 480p@60Hz,
576i@50Hz, 576p@50Hz, 720p@50/60Hz,
1080i@50/60Hz, 1080p@24/25/30/50/60Hz
PCM, LPCM, DTS HD, DTS Audio
0.7~1.2Vp-p(TMDS)
5Vp-p(TTL)
≤8m (AWG24)
≤8m (AWG24)
≤70m
Implementation of the standard: IEC61000-
4-2
1a Contact discharge level 4 (8KV)
1b Air discharge level 4 (15KV)
-20~60°C
-30~70°G
0~90%RH
75.0(L) x 85.0(W) x 20.0(H) mm
Aluminium alloy material + crystal panel
Grit blast
Black
TX: 180h RX: 180g
ensures that the product is conformed to the basic European standards and
®
HDMI KVM EXTENDER
OVER NETWORK CABLE
