HDBitT HDMI POE Extender 4K
FAq
q: TV display "Waiting for connection" on the right corner?
A: Please check if the power supply of TX (Sender) and switcher (if
used) is connected, and make sure connecting cable is firmly.
q: TV display "Please check the TX input signal" ?
A: 1) please check if there is a HDMI signal input of TX.
2) Try to connect the signal source directly to display device to see
if there is signal output from source device or change the signal
source, HDMI wire and try again.
q: Display not fluent, not stable?
A: 1) Please check the cable length between the TX to switch, the
switch to the RX and the connection between each level is within
the required range.
2) Click the "reset" button on the TX/RX front panel, reset and
reconnect.

SPECIFICATIOn

HDMI signal
Transport protocol
Support resolutions
network cable
Transmission distance
Ir Signal
Working temperature
Power Supply
Power consumption
Dimensions
Input POE
Weight
Color
Maintenance: clean only with a dry cloth. Do not use cleaning solvents
or abrasives.
Warranty: no guarantee or liability can be accepted for any changes and
modifications of the product or damage caused due to incorrect use of this
product.
In compliance with EU Directive WEEE this product is marked with
this symbol. It means that used electrical and electronic products
should not be mixed with general household waste. There is a
separate collections system for these products in compliance with
WEEE directive, otherwise contaminative and hazardous substances can
pollute the environment.
With the CE sign, Techly
the basic European standards and directives.
Compatible with HDCP
HDBitT
480i@60Hz, 480p@60Hz, 576i@50Hz,
576p@50Hz, 720p@50/60Hz,
1080i@50/60Hz, 1080p@50/60Hz,
4Kx2K@24/25/30Hz
UTP/STP Cat5E/6
Up to 120m transmission distance for
1080p 60Hz Full HD over single CAT6
Supports 20-60KHz IR devices
0°C – 60°C
DC5V/2A (adapter not included)
TX: 4.5W; RX: 3.5W
119 (L) x 94 (W) x 23.8 (H) mm * 2pcs
Support IEEE802.3af (Input power 10W)
TX: 275g RX: 275g
Black
ensures that the product is conformed to
®
EN En
