Specification - Techly IDATA EXT-E223 User Manual

EN - 8

SPECIFICATION

Power supply
HDMI performance and
interface
Transmission distance
Protection level
Operating environment
Body properties
Maintenance: clean only with a dry cloth. Do not use cleaning solvents or abrasives.
Warranty: no guarantee or liability can be accepted for any changes and modifications of the product
or damage caused due to incorrect use of this product.
In compliance with EU Directive WEEE this product is marked with this symbol. It means that
used electrical and electronic products should not be mixed with general household waste.
There is a separate collections system for these products in compliance with WEEE directive,
otherwise contaminative and hazardous substances can pollute the environment.
With the CE sign, Techly
standards and directives.
WWW.TECHLY.COM
Voltage/ Surrent
Power consumption
HDMI compliance
HDCP compliance
HDMI resolution
Supports audio formats
Input and output TMDS signal 0.7 ~ 1.2Vp-p (TMDS)
Input and output DDC signal
Input cable lengh
Output cable lengh
Cat6/6A/7
Electrostatic protection of the
whole machine
Working temperature
Storage temperature
Humidity (no condensation)
Dimension
Material
Color
Weight
ensures that the product is conformed to the basic European
®
HDMI EXTENDER OVER
CAT.6/7 CABLE WITH EDID
DC 5V /500mA
TX <2.5 W RX <2.5 W
HDMI 1.3
HDCP 1.4
800x600, 1024x768, 1280x720,
1280x960, 1366x768, 1440x900,
1680x1050, 1920x1080, 480i@60Hz,
480p@60Hz, 576i@50Hz,
576p@50Hz, 720p@50/60Hz,
1080i@50/60Hz,
1080p@24/25/30/50/60Hz
PCM, LPCM, DTS HD, DTS Audio
5Vp-p (TTL)
≤ 8m (AWG24)
≤ 8m (AWG24)
≤ 70m
Implementation of the standard:
IEC61000-4-2
1a Contact discharge level 4 (8KV)
1b Air discharge level 4 (15KV)
-20° a 60°C
-30° a 70°C
0 ~ 90% RH
75 (L) x 80 (W) x 18 (H) mm
Aluminum alloy material
Black
TX: 160g RX: 160g
