Telephone
Ports
Base
Station
Power
Pairs
Base
Station
Data
Pairs
UNUSED
PN: 1725-36096-001_J.doc
Two-wire analog or digital demarc block
The demarc block for the two-wire analog or digital interface should
be wired as follows.
tip
LINE1
ring
tip
LINE 2
ring
tip
LINE 3
ring
tip
LINE 4
ring
tip
LINE 5
ring
tip
LINE 6
ring
tip
LINE 7
ring
tip
LINE 8
ring
tip
LINE 9
ring
tip
LINE 10
ring
tip
LINE 11
ring
tip
LINE 12
ring
tip
LINE 13
ring
tip
LINE 14
ring
tip
LINE 15
ring
tip
LINE 16
ring
UNUSED
1 & 2
3 & 4
1
2
3
4
Two-wire Connector
Run Cable for System
25 PAIR MALE
CONNECTOR
CABLE TO
MCU
CONNECTOR A
25
