- Page 1 SpectraLink 6300 MCU T1 Remote Module Installation SpectraLink 6000 System July 2008 Edition 1725-36126-001 Version K...
- Page 2 SpectraLink 6300 MCU: T1 Remote Module Installation: SpectraLink 6000 System Trademark Information Notice Polycom® and the logo designs Polycom, Inc. has prepared this document for SpectraLink® use by Polycom personnel and customers. The LinkPlus drawings and specifications contained herein Link...
-
Page 3: About This Guide
This document explains installation of the Polycom SpectraLink 6000 System (MCS300) Remote T1 Module. The installation process connects the SpectraLink 6300 MCU Primary Shelf in one location with an Expansion Shelf in a remote location, via T1 facilities. Polycom Model Numbers... -
Page 4: Customer Support
SpectraLink 6300 MCU: T1 Remote Module Installation: SpectraLink 6000 System Customer Support Polycom wants you to have a successful installation. If you have questions please contact our Customer Support Hotline at (800) 775-5330. The hotline is open Monday through Friday, 6 a.m. -
Page 5: Table Of Contents
Contents About this Guide ..............3 Polycom Model Numbers..............3 Related Documents................3 Customer Support................4 Icons Used in this Document ............4 Remote Installation Overview............7 Remote Installation Steps (Overview) ..........9 Site Preparation..............11 Required Materials Provided by Customer ........11 T1 Configuration Requirements .............12 Check Components................13 Install T1 Remote Module at Local Site ........15... - Page 6 SpectraLink 6300 MCU: T1 Remote Module Installation: SpectraLink 6000 System Configure Remote System ............27 Configure Remote Shelf ..............27 Master Clock Configuration ............28 Test System ..................29 Site Certification ..............31 Installation Forms ..............33 Site Preparation Checklist..............33 Base Station Location Worksheet............35 Extension Assignments Worksheet ..........36 Customer Acceptance Form ............37...
-
Page 7: Remote Installation Overview
Remote Installation Overview Networking the SpectraLink 6000 System allows installation of expansion shelves at remote locations. T1 circuits are used to provide the connection from the System Controller shelf to each Remote Expansion shelf. As many as 19 expansion shelves may be supported by the system, and up to 18 of these shelves may be installed in remote locations from the System Controller shelf. - Page 8 SpectraLink 6300 MCU: T1 Remote Module Installation: SpectraLink 6000 System Location A - Local Location B - Remote Shelf 3 - Expansion Shelf Shelf 1 - Primary Shelf Intershelf Junction Panel Shelf 4 - Expansion Shelf Shelf 2 - Expansion Shelf Shelf 20 - Expansion Shelf PN: 1725-36126-001_K.doc...
-
Page 9: Remote Installation Steps (Overview)
Remote Installation Steps (Overview) Follow these steps to install the T1 Remote Module. Detailed instructions for each of these steps are contained in this document and other relevant documents in the SpectraLink 6300 MCU System documentation. 1. Prepare site and check components. -
Page 11: Site Preparation
If the steps are not already completed refer to each individual section for details. 1. At the local site, install and test Primary Shelf and Expansion Shelves. Refer to SpectraLink 6300 MCU: Installation for information. 2. At the remote site: a. -
Page 12: T1 Configuration Requirements
SpectraLink 6300 MCU: T1 Remote Module Installation: SpectraLink 6000 System RJ-45 Cable For network clocked T1 facilities, an RJ-45 cable is required to connect the designated Master Clock T1 Module to the Intershelf Junction Panel. T1 Configuration Requirements T1 circuits will connect expansion shelves directly to the System Controller shelf via the Polycom provided Intershelf Junction Panel. -
Page 13: Check Components
Site Preparation • From the CSU, the T1 circuit must be provided to the SpectraLink system on an RJ-48C modular connector. • The CSU must have an independent power supply, per manufacturer specifications. Check Components The following items should be at the installation site. Cables Two 12-foot RJ-45 cables with each Expansion Shelf Controller (CSC300). -
Page 15: Install T1 Remote Module At Local Site
Install T1 Remote Module at Local Site Before installing the hardware at the remote site, the Primary shelf at the local site must have a T1 Remote Module (CRC301) installed. Install one Remote Module for each remote shelf to be installed. Slide the Remote Module into slot or slots through... - Page 16 SpectraLink 6300 MCU: T1 Remote Module Installation: SpectraLink 6000 System Network clocked T1 facilities If the T1 facilities are Network Clocked, one T1 Remote Module must be designated as the Master Clock Source. Connect the port on Sync IN this T1 Remote Module to port on the Intershelf Junction Panel.
- Page 17 Install T1 Remote Module at Local Site CRC-301 TIMING MASTER To AUX Port on Intershelf SYNC Junction Panel for Net Clocked T1 ALARM SYSTEM CONTROLLER RJ45 to Intershelf Junction Panel SC/A EXPANSION SHELF CONTROLLER SC/B LIKOK DS1 A T1 connection Module 3-7 on remote LIKOK DS1 B...
-
Page 19: Install System At Remote Site
1/4” minimum length. Wall mount At this point in the installation process, there should be a backboard securely fastened to the wall and mounting screws partially inserted into the backboard. See SpectraLink 6300 MCU: Installation for more information. PN: 1725-36126-001_K.doc... -
Page 20: Connect Power To Shelves
Connect Power to Shelves Polycom recommends that a licensed electrician install the -48V DC power supply and connect power to the shelves. See SpectraLink 6300 MCU: Installation - Connect Power to Shelves, for more information. Install Cards The shelf diagram below shows a fully loaded Expansion Shelf. Any type of Interface Module can be installed in slots 3 through 12. - Page 21 Install System at Remote Site Cards contain components that may be damaged by electrostatic discharge. Before handling any of the cards, the installer must attach the grounding strap (included in the Administration Kit) to his or her wrist, and attach the other end of the strap to ground. Only handle the cards by their edges.
-
Page 22: Connect Cables To T1 Remote Module
SpectraLink 6300 MCU: T1 Remote Module Installation: SpectraLink 6000 System T1 Remote Expansion Shelf Interface Modules Module Controller Slot 2 Slots 3-12 RS-232 CRC-301 DISABLE DISABLE DISABLE DISABLE DISABLE DISABLE DISABLE DISABLE DISABLE DISABLE TIMING MASTER NORMAL NORMAL NORMAL NORMAL... -
Page 23: Connect Multiple Remote Shelves
Install System at Remote Site Connect Multiple Remote Shelves If the remote site consists of more than one remote shelf, the shelves must be connected to each other. Connect the IPC cable from the port of the T1 Remote Sync OUT Module on the first shelf to the port of the T1 Remote Module Sync IN... - Page 24 SpectraLink 6300 MCU: T1 Remote Module Installation: SpectraLink 6000 System CRC-301 TIMING MASTER SYNC From sync "Out" if more than one remote shelf To sync "In" if more ALARM than one remote shelf SYSTEM CONTROLLER SC/A EXPANSION SHELF CONTROLLER RJ-45 to Expansion Shelf...
-
Page 25: Connect Demarc Block Rj-21 Cables To Interface Modules
Install System at Remote Site Connect Demarc Block RJ-21 Cables to Interface Modules Connect the male RJ-21 connector from the appropriate demarcation block to the designated RJ-21 connector ( ) on each Interface Module. Secure the cables using the keeper. Dress the cables by wire wrapping the cable at the rear of the shelf. -
Page 27: Configure Remote System
Configure Remote System Use the Operator’s Console to enter configuration information for the Remote Expansion Shelves. Configure Remote Shelf 1. From the Operator’s Console, press F1, Supervisor State Display 2. Use the arrow keys to highlight the number of the Remote Shelf to be added ( through ), and press Enter. -
Page 28: Master Clock Configuration
SpectraLink 6300 MCU: T1 Remote Module Installation: SpectraLink 6000 System Select to turn on T1 B. T1 B State T1 On Leave the default (None) or select External Port if Far Sync Source the far sync source is an external port. -
Page 29: Test System
Configure Remote System Test System The system should now be tested to ensure that it is functioning correctly. See section 9 Test System, in the SpectraLink 6300 MCU: Installation manual, for more information. PN: 1725-36126-001_K.doc... -
Page 31: Site Certification
From the Operator’s Console, copy the PCS.CFG file to diskette. From the Operator’s Console, press F1 ( ) then select Supervisor State . See the SpectraLink 6300 MCU: Dump Config to PCS.CFG Operator’s Console document for more information. • Give the system administrator a map of the system showing the final Base Station locations at local and remote sites. -
Page 33: Installation Forms
Copy these forms as needed. Be sure to maintain completed forms for future reference. Site Preparation Checklist If upon arrival the Polycom field service engineer determines that the pre-installation work has not been completed correctly, the engineer has two options: 1) The engineer can leave the site and reschedule the... - Page 34 SpectraLink 6300 MCU: T1 Remote Module Installation: SpectraLink 6000 System The Base Station cables are terminated at the appropriate cross- connect blocks. Analog or digital ports, one per handset, from the switch are terminated at the appropriate cross-connect block and the block is labeled with the extensions.
-
Page 35: Base Station Location Worksheet
Installation Forms Base Station Location Worksheet Shelf Number: ________ Interface Module: ________ Location Interface Module Base Station # (e.g.: building, floor #, detailed description) Circuit # Base Station 1 Base Station 2 Base Station 3 Base Station 4 Base Station 5 Base Station 6 Shelf Number: ________ Interface Module: ________ Location... -
Page 36: Extension Assignments Worksheet
SpectraLink 6300 MCU: T1 Remote Module Installation: SpectraLink 6000 System Extension Assignments Worksheet Shelf: _______ Interface Module: _______ Interface Handset Handset # Ext. # Name Module Comment Serial # Circuit # Handset 1 Handset 2 Handset 3 Handset 4 Handset 5... -
Page 37: Customer Acceptance Form
Installation Forms Customer Acceptance Form Customer Name: _____________________________________________________________________ Lease number (if applicable):___________________________________________________________ Schedule number (if applicable):________________________________________________________ This document certifies that _____________________________________________, acting as the representative of ________________________________________, accepts the installation of the SpectraLink Wireless Telephone System as set forth on schedule number____________________ completed on _______________________________, 200___. - Page 38 SpectraLink 6300 MCU: T1 Remote Module Installation: SpectraLink 6000 System The terms and conditions of original Quotation and Sales Agreement apply to all equipment listed above. _____ I accept the installation of the SpectraLink system as complete. _____ I decline the installation of the SpectraLink system because:...
-
Page 39: Safety And Regulatory Notices
Safety and Regulatory Notices WARNING: Changes or modifications to this equipment not approved by Polycom may cause this equipment to not comply with part 15 of the FCC rules and void the user’s authority to operate this equipment. WARNING: Polycom products contain no user-serviceable parts inside. -
Page 40: Fcc Part 68
SpectraLink 6300 MCU: T1 Remote Module Installation: SpectraLink 6000 System FCC Part 68 This equipment complies with Part 68 of the FCC rules and the requirements adopted by the Administrative Council for Terminal Attachments (ACTA). The SpectraLink 6300 MCU product identifier US:2HWXDNANCRC301 is located on the unit’s PWBA. - Page 41 This equipment is not intended to be serviced or repaired by the customer. Please contact Polycom in the above details for support. Tariffs Connection to party line service is subject to state tariffs. Contact the state public utility commission, public service commission or corporation commission for information.
-
Page 43: Index
Index Intershelf Junction Panel........15 Base station location form........35 JPI300 ..............15 Cards Installing............15, 21 Master Clock............28 Channel Service Unit..........12 Configuration Requirements T1 12 Network Clocked T1 ..........16 CSU .................12 Configuration ...........28 Customer Support Hotline ........4 Power..............20 Demarc block............25 Diagram, Remote Installation .......7 Remote Installation Diagram ........7 Remote Installation, Steps ........9 Expansion Shelf... - Page 44 SpectraLink 6300 MCU: T1 Remote Module Installation: SpectraLink 6000 System Network Clocked ..........16 Installing at remote site ........21 T1 Remote Module Telephone lines .............25 Connect to Expansion Shelf ......22 Testing the system ..........29 Installing at local site ........15 PN: 1725-36126-001_K.doc...
