Install Outdoor Base Stations
PN: 1725-36096-001_J.doc
Outdoor Base Stations are equipped with a protective enclosure,
designed to be mounted to a wall or pole. After the enclosure is
mounted, the Base Station is inserted in the enclosure and connected.
Only RCO Base Stations can be used outdoors.
The customer's wire contractor is responsible for wiring and
mounting the outdoor Base Station enclosure. The contractor is
responsible for supplying screws, brackets, and other appropriate
hardware.
Wire and connect outdoor base stations
If the wiring for a Base Station exits a building - whether to reach
an outdoor Base Station location or to reach a Base Station in
another building - it should be equipped with primary protection
according to the NEC and/or local codes.
Wiring that exits the building must also be protected at both ends
by a Quick Clip Fuse from Illinois Tool Works, Linx Division, model
number SCP-2X2. Insert the Quick Clip fuses in place of bridging
clips on a 66 block for the non-internal Base Station circuits.
1. Mount the outdoor Base Station enclosure to a wall or pole. The
enclosure should be attached at the highest point available that
will provide central coverage for the outdoor area.
2. Insert the Base Station cable through the compression fitting and
tighten the fitting.
3. Wire the Base Station connector just as you wired the RJ-45
connectors for the indoor Base Stations.
4. Place the Base Station inside the enclosure with the part number
label facing the back of the enclosure.
5. Screw the protective cover onto the Base Station enclosure.
