10.2 Software samples

Functionality
SAMPLE00
Transducer
SAMPLE01
SAMPLE02
SAMPLE03
SAMPLE04
SAMPLE05
Digital SAMPLE01
inputs SAMPLE02
SAMPLE03
SAMPLE01
Digital
SAMPLE02
outputs
SAMPLE03
Timer SAMPLE01
SAMPLE02
Table 10-2: Supported software samples
Sample
number
Show information of a transducer channel
Read 1 transducer channel without interrupt.
Read 1 transducer channel with interrupt.
Several transducer channels without interrupt.
Several transducer channels with interrupt.
Test sequence acquisition with interrupt
Read 1 digital input
Read 2 digital inputs
Read 4 digital inputs
Test 1 digital output with/without output memory
Test 2 digital outputs with/without output memory
Test 4 digital outputs with/without output memory
Initialise 1 timer in mode 2 without interrupt, start the timer.
Read the timer value.
Initialise 1 timer in mode 2 with interrupt, start the timer.
Read the timer value. When an interrupt occurs, stop the timer
and quit the program.
