6.1.1 Standard cables: ST3701, ST3701-5 und ST3701-10

The standard cables have the following characteristics in common:
Connectable to all versions of the APCI-3701
-
Round cable, twisted pairs
-
50-pin female connector on 50-pin male connector
-
They differ from each other only in the cable length.
Recommendation:
The standard cables are considered for the use of standard transducers, e.g. Tesa,
Schaevitz, etc. in common industrial environment.

6.1.2 1-channel-cables: ST3701-1-HB und ST3701-1-LVDT

The standard delivery of the APCI-3701-1 always contains one of the both
1-channel-connection cables (whereas, additionally, both cable types can be
ordered separately).
The both cables have the following characteristics in common:
Connectable directly to a APCI-3701-1
-
D-SUB 50-pin female connector with hoods, shielded on binder
-
Length 2 m
-
5-pin female connector with screw cap
-
They differ from each other only in the transducer types that can be connected:
Connectable directly to a APCI-3701
with a HB-transducer
Recommendation:
The cables are considered especially for the following applications:
Block gauge test
-
Roundness test
-
Major diameter test at rotating parts
-
24
ST3701-1-HB ST3701-1-LVDT
Connectable directly to a APCI-3701
with a LVDT-transducer
