- Page 1 Function Description Digital inputs/outputs APCIe-1711, CPCIs-1711, APCI-1710 and CPCI-1710 Multifunction counter board, optically isolated Edition: 03.03-09/2017 DIN EN ISO 9001:2015 certified...
- Page 2 The content of this manual and the technical product data may be changed without prior notice. ADDI-DATA GmbH reserves the right to make changes to the technical data and the materials included herein.
-
Page 3: Warning
If the instructions are ignored, the board, the PC and/or peripherals may be destroyed. WARNING! Designates a possibly dangerous situation. If the instructions are ignored, the board, the PC and/or peripherals may be destroyed and persons may be endangered. www.addi-data.com... -
Page 4: Table Of Contents
Block diagram: “Digital I/O” function..................7 Fig. 1-2: Pin assignment: 50-pin D-Sub male connector (4 Digital I/O modules) .........9 Fig. 1-3: Pin assignment: 78-pin D-Sub female connector (APCIe-1711 and CPCIs-1711)....10 Fig. 1-4: Digital I/O connection example ....................12 Tables Table 1-1: Board versions with “Digital I/O” function................6 Table 1-2: Used signals ..........................8... -
Page 5: Chapter Overview
This document solely describes the function “Digital I/O”. For general information on the APCIe-/CPCIs-1711 or APCI-/CPCI-1710, please read the respective Technical Description of these boards (see PDF links). It contains, for example, the chapter “Inserting and installing the board” that supports you in commissioning. www.addi-data.com... -
Page 6: Function Description
Optical isolation of the inputs and outputs through opto-couplers to prevent ground loops 1.1 Board versions with “Digital I/O” function NOTICE! With the 24 V version of the APCIe-1711, CPCIs-1711 or APCI-1710, the “Digital I/O” function can be used only to a limited extent. -
Page 7: Block Diagram
* Pin Ax or Bx: Only the 24 V input can be used and not the 24 V output. The I/O specifications of the different board versions are available in the Technical Description of the APCIe-/CPCIs-1711 or APCI-/CPCI-1710 (see PDF links). 1.2 Block diagram Fig. 1-1: Block diagram: “Digital I/O” function www.addi-data.com... -
Page 8: Used Signals
Digital input DIG_IN_Gx 24 V / optional 5 V Digital input DIG_OUT_Hx 24 V** Digital output x = Number of the function module (0-3) * 24 V with 24 V board version ** APCIe-/CPCIs-1711: 5-36 V, APCI-/CPCI-1710 10-36 V www.addi-data.com... -
Page 9: Pin Assignment: Function Modules
Pin 34: see Technical Description of the board This pin assignment also applies to the APCIe-1711 or CPCIs-1711 if the cable ST1711-50 is connected to the 78-pin D-Sub female connector of the board. For further information on this, please refer to the Technical Description of the APCIe-1711 and CPCIs-1711 (see PDF link). -
Page 10: Connecting The Signal Generators
Function description Digital I/O Fig. 1-3: Pin assignment: 78-pin D-Sub female connector (APCIe-1711 and CPCIs-1711) FM = Function module * Pins 52 and 72: see Technical Description of the board 1.5 Connecting the signal generators 1.5.1 Connection to the screw terminal panel On the screw terminal panel PX8001, the pins of the 50 pin D-Sub female connector and the terminals connected to them are numbered in the same way. -
Page 11: Table 1-3: Connection Of The Signal Generators To The Screw Terminal Panel
Digital input DIG_IN_Gx 24 V / opt. 5 V Digital input DIG_OUT_Hx 24 V** Digital output x = Number of the function module (0-3) ** APCIe-/CPCIs-1711: 5-36 V, APCI-/CPCI-1710 10-36 V * 24 V with 24 V board version www.addi-data.com... -
Page 12: Connection Example
In order to use the “Digital I/O” function, the following steps need to be performed: 1. Select the function module(s). 2. Select the channels. 3. Connect the signals. 4. Initialise the A and B channels as inputs or outputs. 5. Control the outputs. 6. Read the inputs. www.addi-data.com... -
Page 13: Standard Software
The API software functions supported by the board are listed in an HTML document. A description of how to access the respective file can be found in the document “Quick installation PC boards” (see PDF link), in the chapter “Standard software”. www.addi-data.com... -
Page 14: Appendix
Appendix Digital I/O 3 Appendix 3.1 Index Block diagram 7 Pin assignment 9 Board versions 6 Signals 8 Connection Standard software 13 Signal generators 10 Connection example 12 www.addi-data.com... -
Page 15: Contact And Support
Contact and support Digital I/O 4 Contact and support Do you have any questions? Write or call us: Address: ADDI-DATA GmbH Airpark Business Center Airport Boulevard B210 77836 Rheinmünster Phone: +49 7229 1847-0 Fax: +49 7229 1847-222 E-mail: info@addi-data.com Manual and software download from the Internet: www.addi-data.com...
