Technical data
Energy requirements:
- Operating voltage of the PC: .................. 5 V ± 5%
- Current consumption (without load): ..... typ. see table ± 10%
+ 5 V from PC
WARNING !
The cooling components and the DC/DC connector can warm
up during the board operation.
♦ Install the board in the PC so that cooling air can flow easily between the
different inserted boards.
♦ Before removing the board from the PC, wait until it sufficiently cooled
down.

4.4.1 Sinus generator

Output signal: ........................................... sinus
Possible frequency values

Table 4-1: Available frequency values for the sinus generator

Edge frequency of the high-pass filter (-3 dB): 230 Hz
Output voltage: ......................................... can be set between 0.707 V rms
Output current: .......................................... ± 260 mA max.
Offset voltage: .......................................... ± 1 mV typ.
Harmonic distortion: ................................. 0.75 % typ.
Duty cycle: ................................................ 50 % typ.
14
APCI-3701-8 APCI-3701-16
0.48 A
1.993 kHz
3.005 kHz
3.986 kHz
4.883 kHz
6.104 kHz
6.975 kHz
8.138 kHz
0.58 A
9.765 kHz
10.851 kHz
12.207 kHz
13.021 kHz
13.951 kHz
16.276 kHz
19.531 kHz
and 3.5 V rms
(Duty Cycle adjusted to 50%)
APCI-3701
