APCI-3701

11.3 Board information

After starting the Set3701 application, the first board information can be
visualised automatically.
If you have several APCI-3701 boards in you PC:
♦ Double-click on the board icon
An animated menu opens.
♦ Double-click on the required board to select it

11.4 Transducer database

♦ Double-click on the main menu icon for activating the menu "Transducer
database"
The animated menu opens.
SET3701: Calibration and update tool
Selected board
Number of channels
Windows device number
Board bus number
Board base address
Board interrupt
Board serial number
Revisionsnummer der
Firmware
53
