Technical data
4.5

Technical data of the accessories

4.5.1 Connection boxes and cables of the standard versions

Version
PX3701HB-16
PX3701HB-8
PX3701LVDT-16
PX3701LVDT-8

Connection box

Housing: ................................................... Aluminium die-cast
The signal connections can be labelled
Protection: ................................................. protecting cap for flange socket,
Transducer connection: ............................. 8 or 16 x 5-pin flange socket
See Connection of inductive transducers
Connector: ................................................ 50-pin SUB-D female connector
Dimensions (L x W x H):
PX 3701-8: ................................................ 80 x 57 x 120 mm
PX 3701-16: .............................................. 80 x 57 x 250 mm
Fastening : ................................................. through 2 mounting points
Temperature range: ................................... 0 to 60 °C

Cable specifications

Cable length: ............................................. 2 m, 5 m or 10 m
Connectors: ............................................... 50-pin SUB-D female connector (board)
Shield: ....................................................... twisted-pair leads with common shield
16
Number of connected transducers
16 half-bridge transducers
8 half-bridge transducers
16 LVDT transducers
8 LVDT transducers
dustproof, IP54
DIN 45322
for connecting the cable ST3701
within the enclosure bottom
to 50-pin SUB-D male connector
(connection box)
APCI-3701
Connection cable
ST3701-16
ST3701-8
ST3701-16
ST3701-8
