SunStar SWF/C Series User Manual

SunStar SWF/C Series User Manual

Two-head automatic embroidery machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

USER ' ' S MANUAL
TWO-HEAD AUTOMATIC
EMBROIDERY MACHINE
FOUR-HEAD AUTOMATIC
EMBROIDERY MACHINE
SIX-HEAD AUTOMATIC
EMBROIDERY MACHINE
EIGHT-HEAD AUTOMATIC
EMBROIDERY MACHINE
SIX-HEAD AUTOMATIC
EMBROIDERY MACHINE
(Compact Type)
SWF/C-Series
S S u u n n S S t t a a r r C C O O . . , , L L T T D D . .
M M M M E E - - 1 1 0 0 0 0 4 4 2 2 2 2

Advertisement

Table of Contents
loading

Related Manuals for SunStar SWF/C Series

Summary of Contents for SunStar SWF/C Series

  • Page 1 USER ’ ’ S MANUAL TWO-HEAD AUTOMATIC EMBROIDERY MACHINE FOUR-HEAD AUTOMATIC EMBROIDERY MACHINE SIX-HEAD AUTOMATIC EMBROIDERY MACHINE EIGHT-HEAD AUTOMATIC EMBROIDERY MACHINE SIX-HEAD AUTOMATIC EMBROIDERY MACHINE (Compact Type) SWF/C-Series S S u u n n S S t t a a r r C C O O . . , , L L T T D D . . M M M M E E - - 1 1 0 0 0 0 4 4 2 2 2 2...
  • Page 2 1. THIS IS AN INSTRUCTION FOR SAFE USE OF AUTOMATIC EMBROIDERY MACHINES. READ THOROUGHLY BEFORE USE. 2. CONTENTS IN THIS INSTRUCTION MAY CHANGE, WITHOUT PRIOR NOTICE, FOR IMPROVEMENT OF MACHINE QUALITY AND THUS MAY NOT CORRESPOND TO THE MACHINE YOU PURCHASED.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS CHAPTER 1 SAFETY RULES ........................ 1-1 1-1) DELIVERY OF YOUR MACHINE..................1-1 1-2) INSTALLATION........................1-2 1-3) MACHINE OPERATION ...................... 1-3 1-4) REPAIR........................... 1-3 1-5) PLACEMENT OF WARNING STICKERS ................1-4 1-6) CONTENTS OF WARNING STICKERS ................1-5 CHAPTER 2 INSTALLATION AND MACHINE ASSEMBLY ............
  • Page 4 7-4-4) REPETITION WORK ..................7-32 7-4-5) DATA SET-UP ..................... 7-37 7-4-6) EMBROIDERY DESIGN EDITING ..............7-42 7-4-7) FRAME MOVEMENT ..................7-51 7-4-8) FLOAT (NON-STITCHING FUNCTIONS) ............7-55 7-4-9) MACHINE DATA SET-UP ................. 7-56 7-4-10) THE FLOPPY FUNCTIONS ................7-60 7-4-11) MANUAL CUTTING ..................7-63 7-4-12) OFFSET SET-UP ....................

  • Page 5: Chapter 1 Safety Rules

    CHAPTER SAFETY RULES The following set of safety rules categorized as , and indicates possibilities of DANGER WARNING CAUTION physical or property damages if not fully observed. : These safety instructions MUST be observed to be safe from danger when installing, delivering, or DANGER repairing the machine.

  • Page 6: 1-2) Installation

    2) Using a Forklift Make sure that size and weight of the forklift is sufficient to support the machine. Use the pallet to place the machine so that its center is on the forklift arm (see [Fig.1-2]). Lift the machine carefully so that the machine does not tilt to either side.

  • Page 7: 1-3) Machine Operation

    1-3) MACHINE The SWF Automatic Embroidery Machine is designed for applying OPERATION embroidery to fabric and other similar materials. Pay careful attention to the stickers on certain WARNING CAUTION parts of the machine. Make sure to observe the following when operating the machine: 01) Read thoroughly and fully understand the manual before operating the WARNING...

  • Page 8: 1-5) Placement Of Warning Stickers

    Observe the directions on ALL warning stickers placed on the machine as 1-5) Placement of reminders for your safety. Warning Stickers 1) Location of Warning Stickers Open the upper shaft cover of each head and supply the designated oil. Fire or death may be caused by high voltage electric shock.

  • Page 9: 1-6) Contents Of Warning Stickers

    1-6) Contents of 1) Warning Warning Stickers Injury may be caused by winding. Be sure to turn off the power before cleaning, lubricating, adjusting or repairing. [ Notice ] Safety cover in the WARNING refers to all covers near the operating parts of the machine. Injury may be caused by moving needle.

  • Page 10: Installation And Machine Assembly

    CHAPTER INSTALLATION AND MACHINE ASSEMBLY Install your machine in an appropriate environment and with adequate electrical supply. Failure to follow the directions may result in machine malfunction. 2-1) ENVIRONMENT ① 0∼40°C (32∼104°F) when the machine is in operation 1) Temperature: ②...

  • Page 11: 2-3) Leveling The Machine

    2-3) LEVELING THE MACHINE The machine must be accurately leveled (especially front and back) to prevent the needle from moving out of position. 1) Use the adjusting bolts installed at the four stands to level the machine (front, rear, left, and right). Use a level gauge.

  • Page 12: 2-4) Assembly Of Peripheral Devices

    2-4) ASSEMBLY OF PERIPHERAL DEVICES 1) Assembling Upper Thread Stand Spool plate support thread holder [Fig.2-4] 2) Assembling Operation Box CN6(Joint Board to I/O Board 40P) CN6(Joint Board to I/O Board 34P) Operation box [Fig.2-5] [Fig.2-6]...

  • Page 13: 2-5) Table Assembly

    2-5) TABLE ASSEMBLY 1) Unscrew the eight clamps underneath the table and the bolts to disassemble the table. Table support Bolts [Fig.2-7] 2) Adjust the table support at an appropriate height and fasten the bolts. Table Table support bolts Table height Work type board tubular...
  • Page 14 3) Insert the table and fasten the bolts and the clamps. Table support Bolts [Fig.2-9] [CAUTION] The table should not be higher than the upper side of the needle plate by 0.5mm for board frame work. If the height difference is over 0.5mm, unfasten the table support bolts, adjust the height, and fasten the bolts back.

  • Page 15: 2-6) Frame Assembly

    2-6) FRAME ASSEMBLY 2-6-1) Tubular Frame 1) Unfasten screws on the tubular frame 2/3, install the tubular frame in the groove of the frame connection plate, and fasten the bolt. [CAUTION] Do not install the tubular frame too close from the X frame. Keep the space at around 2mm. Frame connection plate Tubular frame Fixing hole...

  • Page 16: 2-6-2) Border Frame

    2-6-2) Border Frame 1) Unfasten screws on the tubular frame 2/3 and remove the frame. Tubular frame Fixing bolts [Fig.2-12] 2) Adjust the table height at an appropriate level for border frame work. (See 2.5) TABLE ASSEMBLY) 3) Unfasten screws on the border frame 2/3 and install the border frame in the groove of the X frame connection plate.

  • Page 17: Parts Of The Machine

    CHAPTER PARTS OF THE MACHINE 3-1) SWF/C-U SERIES [Fig.3-1] Machine Body Color Change Y-axis driving system Encoder Table Upper thread holder Emergency stop Main power switch Upper thread stand Head S/B button Leveling base Main shaft drive motor Thread tension Tubular frame Sub support Rotary hook base...

  • Page 18: 3-2) Swf/C-Uh1508-45

    3-2) SWF/C-UH1508-45 [Fig.3-2] Main Body Color Change Emergency stop Leveling base Table Upper thread holder S/B button Sub support Upper thread stand Head Tubular frame Thread detector Main shaft drive Thread tension Border frame Emergency power motor adjustment board Controller box switch Rotary hook base Sub-controller...

  • Page 19: Functions And Features

    CHAPTER FUNCTIONS AND FEATURES 01) EXPANDED MEMORY SIZE The machine can store a maximum of 100 designs. The basic memory size is 2 million stitches. 02) MIRROR IMAGE CONVERSION AND DESIGN DIRECTION You can turn the design from 0°to 359°in the increments of 1°and also reverse the design in the X direction (mirror image).
  • Page 20 12) AUTOMATIC DETECTION OF UPPER AND LOWER THREAD BREAKS ① Spring Type ① The upper and the lower threads are detected by two separate devices. The machine stops automatically when the upper thread breaks or the lower thread is out of the needle (lower thread detector is optional for all machines except for single-head).

  • Page 21: Chapter 5 Functions For Basic Machine Operation

    CHAPTER FUNCTIONS FOR BASIC MACHINE OPERATION 5-1) NAMES AND FUNCTIONS OF PARTS IN OPERATION BOX [ Front Side ] [Fig. 5-1] ① LCD Menu Screen Shows 4 lines of 20 letters and indicates the menu you selected using key ⑥. ②...
  • Page 22 [NOTE] function Selects menu Sets number inputs Completes work: When the machine stops during operation, hold [SET] key until you hear a loud beep. The machine will complete the work (Press [SET] until the RUN MODE indicator light is turned off). ⑦...
  • Page 23 [Right] [Bottom] [Fig. 5-3] [Fig. 5-2] ① Acryl cover: protects the floppy disk drive ② Disk Out: takes the disk out ③ FDD: runs and reads the floppy disk ④ Work Lamp: blinks when FDD is in operation ⑤ COM1: serial port-1 ⑥...

  • Page 24: 5-2) Emergency Power And Start/Stop Buttons

    5-2) EMERGENCY POWER AND START/STOP BUTTONS 5-2-1) Emergency Power Switch When starting the machine from initial stage, ① Turn on the main power ([Fig.5-4]). ② Press the emergency power switch (green color). ③ Emergency power switch will not turn on if the main power is off. Emergency power switch [Fig.5-4] [NOTE]...
  • Page 25 ① START/STOP for starting embroidery and stopping the machine BUTTON OPERATION MACHINE OPERATION Machine starts and embroidery work begins. Press START Hold START Machine “inches (see Note1)” until you release the button. Press STOP Machine stops. [NOTE 1] You cannot perform non-stitching (floating) at the start of the embroidery because the function is not in the start menu.

  • Page 26: 5-3) Emergency Stop

    5-3) EMERGENCY STOP Press EMERGENCY STOP if you have to stop the machine immediately, i.e. machine error. [Fig.5-6] 1) EMERGENCY STOP will turn off the machine. 2) To restart the machine, rotate the main shaft to 100°. 3) Turn the EMERGENCY STOP button off and then on again. [Fig.5-7]...

  • Page 27: 5-4) Lamp On Thread Tension Adjustment Board

    5-4) LAMP ON THREAD TENSION ADJUSTMENT BOARD 1) Switch ① For normal operation, turn the toggle switch on to turn on the indicator lamp. ② If the machine stopped after detecting a thread break, move the frame back to the location of the thread break using STOP button and restart the machine to pick up stitching (design edit).

  • Page 28: 5-5) Needle Stop Clutch

    5-5) NEEDLE STOP CLUTCH As illustrated in [Fig.5-9], the needle bar will not move when you pull the jump clutch lever. Push the level to the opposite direction of the operator to do move needle bar up and down. Jump manual clutch lever [Fig.5-9] The trimmer and the take-up lever continue to move even when the needle bar is stopped by the clutch.

  • Page 29: 5-6) Lamp On Color Change Box(Swf/C-Uh1508)

    (SWF/C-UH1508) 5-6) LAMP ON COLOR CHANGE BOX Needle position lamp on the color change box blinks at the needle bar currently in operation. Needle set lamp blinks when the needle reaches the center of the needle hole on the plate (roller is positioned at the straight line of the color change cam) (see [Fig.5-10] on relationship between the lamp and the line of the color change cam).

  • Page 30: 5-7) Upper Threading And Tension Adjustment

    5-7) UPPER THREADING AND TENSION ADJUSTMENT 1) Upper Threading Upper thread stand Upper thread (from the upper thread stand) Sub thread adjuster Thread tension adjustment board Thread detecting roller Thread detecting board Take-up lever spring Rotary tension disk Main thread tension adjuster Upper thread guide Thread guide...
  • Page 31 Threading the sub Threading the thread Threading the main Threading around the tension adjuster detector roller tension adjuster needle Thread holder Thread guide spring (lower) Thread Sensing Roller One and Thread Guide Disk half turn One turn (Pass through the Rotary Tension Disk middle of shaft) Fix the upper thread...
  • Page 32 3) Take-Up Spring CORRECT WRONG Connect between the take-up spring and the stopper. Take-up spring unable to connect with the stopper Stopper (due to dust or foreign substances in the stopper.) Take-up spring [Fig.5-15] ① Take-up Spring Functions Difference in the length of the upper thread pulled by the take-up lever and pulled by the hook creates tension or looping.

  • Page 33: 5-8) Lower (Bobbin) Threading And Tension Adjustment

    5-8) LOWER (BOBBIN) THREADING AND TENSION ADJUSTMENT 1) Lower Threading ① Use cotton yarn (#80－#120) for your lower thread. ② Threading the bobbin: ⓐ Insert the threaded bobbin into the bobbin case with the thread coming out from the case slot. Pull the thread through the thread guide.
  • Page 34 5-9) THREAD WINDER 1) Lower thread winding ① Insert the bobbin into the thread winder shaft as in [Fig. 5-19]. Wind the bobbin 5-6 times by hand in the thread winding direction. Then press the start button, and the thread winding begins. Knob Thread tension adjusting nut Tension adjusting holder...

  • Page 35: 5-10) Floppy Disks

    [CAUTION 1] Winding the bobbin off-center or uneven as shown below can cause thread breaks, skipped stitches, or thread tangles. [Fig.5-23] [CAUTION 2] Too tight tension of the bobbin thread may block smooth pulling of the thread and cause thread breaks or short tails.
  • Page 36 Inserting the Disk Disk Out [Fig.5-25] ① Press the cover of the disk drive to open (as shown in the left picture of [Fig.5-25]). ② Insert the floppy disk into the drive in the direction shown in the right picture of [Fig.5-25] Taking out the Disk [CAUTION] Do NOT remove a disk from the drive while formatting, reading, or writing the disk.

  • Page 37: 5-11) In And Out Of Designs

    5-11) IN AND OUT OF DESIGNS You can use a floppy disk or a tape reader to read a design with SWF Machine. You can write the design on the floppy disks. See 7.4.1) In and Out of Designs for details. 5-12) RETURN TO PREVIOUS LOCATION IN UNEXPECTED BLACKOUTS Your SWF machine goes back to the location of stop to pick up stitching when the power comes back on after unexpected blackouts.

  • Page 38: 5-13) Needle-Hook Timing Control

    5-13) NEEDLE-HOOK TIMING CONTROL 1) Needle ① It is very important to select the right needle for the type of thread and fabric used. ② Inappropriate needle may cause bad embroidery, thread breaks, skipped stitches, etc. ③ For normal embroidery, use a DB×K5 needle. [CAUTION] DB K5 needle has an eye twice larger than that of DB1 (used for normal sewing).
  • Page 39 ② When inserting the needle, make sure that the groove Needle insert hole of the needle is facing front. Shaft of the needle should be inserted completely into the needle bar. Front groove of the needle groove [Fig.5-27] [CAUTION 1] For special threads such as artificial silk, turn the needle slightly to the right to prevent thread breaks (see [Fig.5-27]).
  • Page 40 4) Relationship between Needle and Hook ① Adjusting Timing between Needle and Hook Default timing of the needle and the hook is set by the main shaft angle of 200° and varies as below. Hook point Top point of hook Hook point Top edge of the needle eye circumference...
  • Page 41 [CAUTION] Functions by Needle Shape ① Size of the hole and groove differs by needle. • Front groove: protects the thread from the heat of the Front groove sewing friction (which may cause thread breaks). • Back groove: helps regulate the hook timing and prevents looping.
  • Page 42 5) Relationship between the Take-up Lever and the Hook Hook point timing is directly related to thread tension and thread breaks. The following pictures show the location of hook when the take-up lever starts to move up from the lower dead stop (main shaft rotation angle: 292°). FAST HOOK TIMING Groove of the hook is in the (A) range.

  • Page 43: 5-14) Assembly And Functions Of Thread Detector

    5-14) ASSEMBLY AND FUNCTIONS OF THREAD DETECTOR 5-14-1) Functions of Thread Detector Detection of the breaks of upper or lower threads prevents ill quality embroidery. The thread- break detector unit contains rollers that sense the smooth feeding of the thread. Any dust, thread remnants, etc. will interfere the rollers’...

  • Page 44: Basic Machine Operation

    CHAPTER BASIC MACHINE OPERATION TURN ON THE MAIN POWER IS THE OPERATIONG SYSTEM INSTALLED? IS THE DESIGN INPUT KEY PRESSED? INSTALL OPERATING SYSTEM ARE THERE PREVIOUSLY WORKED DESIGNS? ARE THERE DESIGNS IN MEMORY? READ DESIGN FROM READ IN DESIGN DISK OR TAPE READ IN THE SET-UP READ IN DESIGN SET-UP PARAMETERS...

  • Page 45: Navigating The Control Panel

    CHAPTER NAVIGATING THE CONTROL PANEL 7-1) INSTALLING THE OPERATING SYSTEM You may have to install an operating system in the event of the deletion of the system due to controller box malfunction or an upgrade to the latest OS version. You will see the program on the screen when: there is no operating system in the memory keys are pressed at the same time in the start screen The first screen you will see when you turn on the main power looks like this:...
  • Page 46 If the machine operating system is not in the memory, or if keys were pressed at the same time, the system installation program will appear (see below). = I N S T A L L P R O G R A M = [Machine Information] 1.
  • Page 47 1. VERSION INSTALL 2. VERSION BACKUP 3. ENCODER SETTING 4. C/C SETTING Press SYSTEM WRITE: 55[%] [>>>>> Insert DISK 2 into the drive and move the cursor to “1. VERSION INSTALL” 1. VERSION INSTALL 2. VERSION BACKUP 3. ENCODER SETTING 4.
  • Page 48 When the installation is completed, the cursor will be at “12. MACHINE 12. MACHINE SETTING SETTING” 13. EXIT Press Select the machine type (check the 1. SWF - T series machine model). 2. SWF - W series If you select “3. SWF - U Series” the 3.
  • Page 49 12. MACHINE SETTING Press 13. EXIT Move the cursor to “13. EXIT” to go 12. MACHINE SETTING to the new program. 13. EXIT Press S Y S T E M C H A N G E . . . You will see this message on your = = = S W F [ W ] B / V x .
  • Page 50 If the selection is incorrect, the machine will not operate normally. CAUTION Machine Model by Series TYPE NAME DESCRIPTION Bridge Type Arm + Flat Table Single-head Wide SWF/ □ –W1201 Embroidery Machine 4-head Flat Embroidery SWF/ □ –WE1204 Machine 6-head Flat Embroidery SWF/ □...

  • Page 51: 7-2) Main Indication Screen

    7-2) MAIN INDICATION SCREEN The screen has two parts: one for machine information and the other for menu display. 1) Machine Information Screen (VFD) Displays the current condition of the machine. You can select one of the four display styles. ①...
  • Page 52 2) Menu Screen (LCD) Displays the set-ups and the main & sub menus selected. ① Set-up There are 10 types of set-up information. Four will be listed at a time. Press UP or DOWN on the right side of the LCD screen to move to another screen. STITCH 16850 COLOR...

  • Page 53: 7-3) The Function Menu

    7-3) THE FUNCTION MENU 7-3-1) Outline of Function Menu reads in or outputs designs In and Output of Designs PP. ~ (7-4-1) basic set-up (scale up/down, rotation, etc.) Basic Set-Up PP. ~ (7-4-2) Auxiliary Work measures length, checks paths, etc. PP.

  • Page 54: 7-3-2) Function Menu Diagram

    7-3-2) Function Menu Diagram DESIGN IN/OUT EMB CALL FDD CALL GNT2910 EXTERNAL INPUT GNT4604 SERIAL PARALLEL EXTERNAL OUTPUT SERIAL DESIGN DELETE PARALLEL DESIGN COPY MEMORY INITIAL AUXILIARY WORK LENGTH MEASURE DESIGN TRACE OPTIMIZE TRACE MACHINE TEST JUMP SOL TEST MACHINE SET-UP WIPER SOL TEST PICKER SOL TEST TRIM SYSTEM TEST...

  • Page 55: 7-4) Use Of Function Menu

    7-4) USE OF FUNCTION MENU 7-4-1) In and Out of Designs When the machine is turned on and the embroidery information loads, press . You will see the following screen: 1. EMB CALL 2. FDD CALL 3. EXTERNAL INPUT 4. EXTERNAL OUTPUT The sub menus for design input and output are: 1.
  • Page 56 12372 5954 7281 17325 Move the cursor to memory #8. 18294 13826 21064 16850 Press 1. EMB CALL 2. FDD CALL 3. EXTERNAL INPUT 4. EXTERNAL OUTPUT Press STITCH 16850 COLOR JUMP Check the menu screen that the design was called with no errors. You can also check it through the D E S I G N # 8 1 6 8 5 0 s t...
  • Page 57 ■ FDD CALL : Reads the Design from the Floppy Disk Ex) Move “GOLF” from the floppy disk to Location#30. Number of stitches:7667. Place the cursor at “2. FDD CALL” . 1. EMB CALL 2. FDD CALL 3. EXTERNAL INPUT 4.
  • Page 58 Move the cursor using the UP and DOWN keys to “30” . SELECT EMPTY ROOM ===> # 30 EMB READ 55[%] Press [>>>>> Function that input automatically The screen shows the copying progress. needle bar of ZSK diskette. (You can select information of needle bar in case of copy design of ZSK NEEDLE SEQ ZSK diskette)
  • Page 59 ■ ■ New Menu for Design Calls ⇒ Revision of the functions in “7.4.1) In and Out of Design” Select a design using EMB CALL or FDD CALL and you will see the following screen. 1. BASIC SETTING 2. NEEDLE SETTING 3.
  • Page 60 ■ ■ EXTERNAL INPUT: Reading Design from Outside 1] GNT2910 2] GNT4604 3] SERIAL 4] PARALLEL 1. GNT2910: reads data from Tape Reader 2. GNT4604: reads data from Tape Reader 3. SERIAL: enables data correspondence between PC and the machine 4.
  • Page 61 The following screen will appear after all data has been read from the tape. To store the data, move the cursor to “YES” and press DO YOU WANT TO SAVE ? [YES] [NO] The tape format is automatically detected as shown above.
  • Page 62 ■ ■ DESIGN DELETE: Deleting Design in Memory Ex) Deleting a design in memory #30 [number of stitches : 7667] Place the cursor at “5. DESIGN DELETE.” 2. FDD CALL 3. EXTERNAL INPUT 4. EXTERNAL OUTPUT 5. DESIGN DELETE Press 5954 7281 17325...
  • Page 63 If you delete a design that is currently in use, you will see the following message: On Machine Information Screen: = = = = S W F - E M B = = = = On Menu Screen: NOT LOAD DESIGN!... ■...
  • Page 64 Press to copy. SELECT EMPTY ROOM ===> # 17 Selecting the memory room. Move to #35 by moving the cursor UP/DOWN or using the numerical keys. SELECT EMPTY ROOM ===> # 35 Press 1. EMB CALL 2. FDD CALL 3. EXTERNAL INPUT 4.
  • Page 65 ■ ■ MEMORY INITIAL: Deleting All Designs in Memory Ex) Deleting all designs in the memory Place the cursor at “7. MEMORY INITIAL” 4. EXTERNAL OUTPUT 5. DESIGN DELETE 6. DESIGN COPY 7. MEMORY INITIAL Press DO YOU WANT TO FORMAT ? [YES] [NO] Move the cursor to “YES”...

  • Page 66: 7-4-2) Basic Set-Up

    7-4-2) Basic Set-up When the machine is turned on and operating system loads, press . This allows the set-up of basic design changes. Set-up items are as follows: ① X_Scale: Reduces or enlarges the design along the X axis (left to right). [100%] [200%] The default is 100% and the allowed range runs from 50% to 200%.
  • Page 67 ④ Mirror: Reverses the design on the X axis, the Y axis, or both. [No] [YES] [Mirror on the X axis] [No] [YES] [Mirror on the Y axis] [No] [YES] [Mirror on the X & Y axis] ⑤ START ST: Selects the start location on the design. You can skip certain number of stitches and start from the desired location.
  • Page 68 ⑥ X SATIN: Sets the width of a satin stitch in the X direction. [Changing the satin width 2mm on each side] [After widening] The setting can increase in increments of 0.1mm on each side. The default is 0 and the range is from 0 to 5. ⑦...
  • Page 69 Move the cursor to set up the X Scale and press X_SCALE [RANGE : 50-200[%]] ==> Input “150” using the numerical keys. X_SCALE [RANGE : 50-200[%]] ==>150 Press 1] X_SCALE : 150[%] 2] Y_SCALE : 100[%] 3] ANGLE 4] MIRROR NO MIRROR X Scale was set at “150”...
  • Page 70 Move the cursor to set up the Angle and press ANGLE [RANGE : 0 - 359 ] ==> Input “45” using the numerical keys and press 1] X_SCALE : 150[%] 2] Y_SCALE : 120[%] 3] ANGLE 4] MIRROR NO MIRROR Use the same procedure to set up MIRROR, START ST, X SATIN and Y SATIN.

  • Page 71: 7-4-3) Auxiliary Work

    Press DOWN once. X[mm] 96.5 Y[mm] 135.0 ANGLE MIRROR The X and Y lengths changed and the Angle is set at 45 degrees. Press 100/18294 st[ Machine Information Screen shows 100 stitches progressed already. 7-4-3) Auxiliary Work Press when the machine is turned on and the operating system loads. You will see a screen like this: 1.
  • Page 72 ■ ■ Length Measure - measuring length between two selected points Use the manual key to reach the standard point. Place the cursor at “1. LENGTH MEASURE” in the sub menu. 1. LENGTH MEASURE 2. DESIGN TRACE 3. OPTIMIZE TRACE Press [ Machine data screen] 0 , Y :...
  • Page 73 ■ ■ Design Trace - tracing outline of the selected design ① This function enables you to quickly check if the X and Y limits of the selected design will fit in the current hoop. ② The arrows in the picture show the path of the design trace. The design will be traced at its furthest points (maximum and minimum X and Y).
  • Page 74 Ex) Calling and tracing a design in memory #5 Call design from #5 using EMB CALL. STITCH 18294 COLOR JUMP Press 1. LENGTH MEASURE 2. DESIGN TRACE 3. OPTIMIZE TRACE Move the cursor to “2. Design Trace” and press FRAME TRACE Frame traces the design with this screen.
  • Page 75 ■ ■ Optimize Trace ① This enables you to quickly check the outline of the selected design by tracing the outline. ② The arrows in the picture show the path of the trace. The design will be traced at its furthest points. If it is too large for the hoop, the frame stops and the message “Frame Limit Error”will appear on the screen.

  • Page 76: 7-4-4) Repetition Work

    7-4-4) Repetition Work Press when the operating system loads. You will see a screen like this: The following parameters must be set for repetition work. 1. X REPEAT: sets the number of X repetitions 2. Y REPEAT: sets the number of Y repetitions 3.
  • Page 77 Moving +20mm Moving –20mm Start point of design (+ 20 mm) Move Move (–20 mm) Start point of design • X/Y PRIORITY Set the priority between X and Y directions. [X set as priority] [Y set as priority] • DESIGN INTERVAL You can select STOP CODE or JUMP CODE to move the design.
  • Page 78 [NOTE] The number of needle bars (color changes) is indicated on the start menu screen. STITCH 18294 COLOR JUMP Ex) Calling a design from memory #5 for repetition work with the parameters set as below Y DESIGN INTERVAL: －40mm X REPETITION: 5 Y REPETITION: 5 X/Y PRIORITY: X X DESIGN INTERVAL: 40mm...
  • Page 79 Input “40” for X design interval and press ==== REPEAT SETTING ==== 4] Y Design Interval -300 - > +300[mm] => Input “–40” for Y design interval and press ==== REPEAT SETTING ==== 5] Y/X Priority Y(0), X(1) => Input “1” to select X as priority and press ==== REPEAT SETTING...
  • Page 80 ==== REPEAT SETTING ==== 6] Design Interval JUMP(0), STOP(1) => ( JUMP) Input “0” for JUMP CODE and press STITCH 457350 COLOR JUMP Press if you want to cancel repetition work. DO YOU WANT TO CANCEL ? [YES] [NO] Move the cursor to “YES” DO YOU WANT TO CANCEL ? [YES] [NO]...

  • Page 81: 7-4-5) Data Set-Up

    7-4-5) Data Set-up Press when the operating system loads and you will see the following screen: There are 2 sub menus for data set-up. 1. EMB FUNCTION: sets parameters for the embroidery work. 2. MACHINE FUNCTION: sets parameters for the machine operation. •...
  • Page 82 ④ AUTO ORIGIN (Return to the start position) This move the frame back to the start position after work is finished. The default is “YES.” Select “0” for “NO” if you do not want to use this function. ⑤ START INCHING (Number of inchings at the beginning) The machine inches slowly when it starts.
  • Page 83 ⑫ ST BACKTACK (Automatic back-tack) This selects a back-tack, a stitch at the start of the embroidery (to prevent thread unraveling). The default is “NO.” ⑬ AUTO BACK (Automatic back stitching after detection of thread break) This sets the number of the stitches that the frame automatically moves back when it detects a thread break. The default is 2 stitches and the range is from 0 to 5 in the increments of 1 stitch.
  • Page 84 ④ SEQUIN This selects the sequin function. The default is “NO” and you can input “1” for “YES.” ⑤ UP_THD SENSE (Upper thread detection) This selects the upper thread sensor function and the number of stitches for detection. Bobbin thread is not detected when this is set at “0.”...
  • Page 85 ⑪ MIN SPEED (Minimum speed limit) This sets the minimum machine speed. The default is 300 rpm and the range is from 300 rpm to the maximum speed limit in the increments of 10 rpm. ⑫ JUMP SPEED This sets the speed limit for jump stitching (frame moves without sewing). The default is 750 rpm and the range is from the maximum to the minimum speed limit in the increments of 10rpm.

  • Page 86: 7-4-6) Embroidery Design Editing

    7-4-6) Embroidery Design Editing Press when the operating system loads and you will see a screen like this: The following sub menus are available for editing the selected design. 1. STITCH EDIT: edits the stitch data of the selected design. 2.
  • Page 87 500] 501] EDIT The cursor is on DEL. Press PREVIOUS if you want to move back to the stitch data. The cursor key is used to select DEL, INS, or Move the cursor to EDIT. EDIT. 500] 501] EDIT Press === STITCH EDIT === X DATA Y DATA...
  • Page 88 Function code change is not on the menu, so press 500] 501] EDIT STITCH 500 data has been changed. Using the same procedure, select STITCH 700 and select EDIT. === STITCH EDIT === X DATA Y DATA FUNCTION : NORMAL(0) Press twice to change the function code.
  • Page 89 Press 700] 701] EDIT STITCH 700 was revised as above. To delete STITCH 800, press cursor key and 800] 801] EDIT Move the cursor to DEL and press 800] 801] EDIT STITCH 800 is deleted and STITCH 801 is now changed to STITCH 800. To insert a stitch in STITCH 900, move the cursor to STITCH 900.
  • Page 90 For data insert, move the cursor to 900] INS and press 901] EDIT STITCH 900 is changed to STITCH 901.X=0, Y=0, and NORMAL CODE was set for STITCH 900. Using the same procedures, set JUMP CODE. 900] 901] EDIT Press to end EDIT DESIGN SAVE ? [YES]...
  • Page 91 Place the cursor at “2.DESIGN DIVIDE” and press DESIGN DIVIDE STITCH= [ST] Input 1000 using the numerical keys and press SELECT EMPTY ROOM ===> # 18 To store sub-design ①, select #35 using the cursor. Press SELECT EMPTY ROOM ===> # 35 To store sub-design ②, select #36 using the cursor.
  • Page 92 Press to check if the original design is separated. Move the cursor to #35. 10898 55961 1000 17294 ■ ■ DESIGN FILTERING: Optimizing the selected design Ex) Editing the design in memory #5: setting the minimum stitch width at over 0.3mm and storing it in memory #17 (number of stitches: 18294) Call the design in #5 and press 1.
  • Page 93 SELECT EMPTY ROOM ===> # 17 Select #17 using the cursor key. Press 1. STITCH EDIT 2. DESIGN DIVIDE 3. DESIGN FILTERING Press to check the editing 11113 10898 55961 17550 number of stitches changed from 18294 to 17550, stored in #17 7-49...
  • Page 94 ■ ■ SPEED CODE: Setting the speed in operation mode Ex) Slowing down the speed while working on design from memory #5 (number of stitches: 18294) from STITCH 1000 to STITCH 2000 Stop the machine at STITCH 1000 by pressing Press to change the speed code...

  • Page 95: 7-4-7) Frame Movement

    7-4-7) Frame Movement (1) Moving Frame During Embroidery Press when the operating system loads and you will see the following screen: 1. DATA ORIGIN 2. ORIGIN 3. POWER RESUME 4. FRAME ANGLE SET ■ ■ DATA ORIGIN (Frame moves back) Your SWF machine remembers the stopped position of the frame when it stops during operation (bar switch, thread break detection, etc.) After you move the frame by frame movement key and do work, you can use the DATA...
  • Page 96 ■ ■ POWER RESUME In case the frame was moved during blackout, this function moves the frame back to the previous position before the blackout. A) Start point of embroidery B) Stop point of embroidery C) Frame moved by POWER RESUME The above three functions are about automatic movement of frame.
  • Page 97 ■ ■ FRAME ANGLE SET Changes the frame feed conditions and sets the main shaft's rotary angle. Moves the cursor to “4. FRAME 1. DATA ORIGIN ANGLE SET”. 2. ORIGIN 3. POWER RESUME 4. FRAME ANGLE SET Press 1. ASTART POINT : 2.
  • Page 98 (2) Moving Frame Before Embroidery Begins Press while the embroidery information is displayed on the menu screen. 1. ASTART POINT : 2. BSTART POINT : When the cursor is in “A/BSTART POINT”, press . Then the following screen appears. A-START POINT RANGE : -10↔...

  • Page 99: 7-4-8) Float (Non-Stitching Functions)

    7-4-8) Float (Non-Stitching Functions) Press when the operating system loads and you will see the following screen: 1. 100 STITCH 2. 1000 STITCH 3. 10000 STITCH 4. COLOR 1. 100 STITCH: forward or backward movement in units of 100 stitches. 2.

  • Page 100: 7-4-9) Machine Data Set-Up

    7-4-9) Machine Data Set-up Press when the operating system loads and you will find the following screen: This indicates the machine settings and information. The sub menus are: 1. MACHINE TEST 2. MACHINE SET 3. ERROR LIST 1. MACHINE TEST: tests solenoid or thread detecting functions. 2.
  • Page 101 ■ ■ MACHINE SET: Sets frame limit Select “2.MACHINE SET,” press and you will find the following screen: The function has three sub-menus. 1. MACHINE SET 2. FRAME ORIGIN 3. FRAME LIMIT SET ① MACHINE SET It sets parameters for machine set-up (selects CUT NEEDLE). •...
  • Page 102 CUTTING NEEDLE SET 1 => USE, 0 => NO Press to end the [100001000000] process. ② FRAME ORIGIN This moves the frame back to the start position. Start position of the frame must be set so the frame can move back to the previous position in case of a power failure.
  • Page 103 Set P1X=100, P1Y=500 using P1X : 100, P1Y : Press P2X : 100, P2Y : Set P2X=1500, P2Y= –500 using P2X : 1500, P2Y : -500 Press ■ ■ ERROR LIST: List of the most recent errors Ex) Reading the latest errors Move the cursor to “3.ERROR LIST”...

  • Page 104: 7-4-10) The Floppy Functions

    7-4-10) The Floppy Functions Press when the operating system loads and you will see a screen like this: 1. FDD SAVE 2. FDD DELETE 3. FDD FORMAT 1. FDD SAVE: copies data in the memory onto a floppy disk. 2. FDD DELETE: deletes the designs in the disk. 3.
  • Page 105 FORMAT : 55[%] [>>>>> [CAUTION] Incorrect selection of disk type may cause damage to the disk. Refer to the disk type indicated on the disk. If the disk information is not available, set “2HD” if there are two holes on the left and the right. Set “2DD” if there is only one hole on the left.
  • Page 106 To copy the design onto a disk, you have to select an output format. In this case, select “1.SWF” and press EMB WRITE : 55[%] [>>>>> 1. FDD SAVE 2. FDD DELETE 3. FDD FORMAT To delete the design copied onto the disk, move the cursor to “2.FDD DELETE”...

  • Page 107: 7-4-11) Manual Cutting

    7-4-11) Manual Cutting Press when the operating system loads and you will see the following screen: TRIMMING OPERATION RUN => START SWITCH CANCEL => PREVIOUS You can perform manual trimming other than the automatic trimming set by DESIGN CODE. Press START on the menu screen and the machine will automatically start trimming.
  • Page 108 1. Start point 2. Stitch for offset 3. Stitch for finish of embroidery 4. Middle offset point 5. Offset point a) ④ : path at the start of the embroidery b) ①→③→① : Movement from the offset stitch to the offset point c) ②→③...

  • Page 109: 7-4-13) Needle Bar Selection

    Set X=600, Y=1500 using and press MIDDLE OFFSET => FRAME MOVE Set X=800, Y=2000 using and press OFFSET POINT => FRAME MOVE 7-4-13) Needle Bar Selection Press when the operating system loads and you will see a screen like this: ==== NEEDLE SELECT...
  • Page 110 Ex) Setting the needle order as 1-2-10-11-12 and arranging offset between 10 and 11 Press when the embroidery information loads ==== NEEDLE SELECT ==== ]: 1 / 1 [END] [INSERT] [DEL] Press “1” numerical key ==== NEEDLE SELECT ==== ]: 1 / 1 [END] [INSERT] [DEL]...
  • Page 111 and “1” for 11 Press ==== NEEDLE SELECT ==== [12AoB ]: 5 / 5 [END] [INSERT] [DEL] and “2” for 12 Press ==== NEEDLE SELECT ==== [12AoBC ]: 6 / 6 [END] [INSERT] [DEL] Press to end set-up ==== NEEDLE SELECT ==== [12AoBC...
  • Page 112 Ex) Using INSERT and DEL to change the needle order from [1-2-10-offset-11-12] to [1-2-3-10-11-12] Press when the embroidery information loads ==== NEEDLE SELECT ==== [12AoBC ]: 1 / 6 [END] [INSERT] [DEL] Move the cursor to A to insert “3” in between “2”...
  • Page 113 Move the cursor to “o” to delete the offset point between A and B ==== NEEDLE SELECT ==== [123AoBC ]: 3 / 7 [END] [INSERT] [DEL] “3” is inserted between 2 and A Press ==== NEEDLE SELECT ==== [123AoBC ]: 3 / 7 [END] [INSERT] [DEL]...

  • Page 114: Error Messages And Correction

    CHAPTER ERROR MESSAGES AND CORRECTION 8-1) MAIN SHAFT MOTOR ERROR MESSAGE ERROR CORRECTION Main shaft is not at the fix Main shaft didn’ t stop at 100° Use a lever to adjust the shaft angle position when machine stopped at 100° Main motor driver irregular signal Turn the main switch OFF and ON Error in main shaft motor driver...

  • Page 115: 8-4) Encoder

    8-4) ENCODER ERROR MESSAGE ERROR CORRECTION Error in A of the main shaft Check cable connection. Turn the Encoder A signal does not vary encoder. main power OFF and ON again. Error in Z of the main shaft Check cable connection. Turn the Encoder Z signal does not vary encoder.

  • Page 116: 8-7) Tape Reader And Communication

    8-7) TAPE READER AND COMMUNICATION ERROR MESSAGE ERROR CORRECTION Error in data read from the tape Re-input the data through the tape Read data error reader. reader. Network system not found! Network device is not connected. Check the network connection. 8-8) MEMORY ERROR MESSAGE ERROR...

  • Page 117: The Control Box

    CHAPTER THE CONTROL BOX 9-1) CHANGING FUSE IN JOINT BOARD OF M/C WITH LESS THAN 12 HEADS Refer to the table below and fill the exact amount of fuse when changing fuse in the joint board. 9-1-1) SWF/ -U Series (excluding SWF/C-UH1508-45) Trimming solenoid Fuse Wiper solenoid...
  • Page 118 9-1-2) SWF/C-UH 1508-45 Jump solenoid, Trimming solenoid Fuse Wiper motor Picker solenoid Fuse Capacity 250V/2A 250V/3A...

  • Page 119: 9-2) Changing Fuse In M/C With More Than 12 Heads

    9-2) CHANGING FUSE IN M/C WITH MORE THAN 12 HEADS Refer to the table below and fill the exact amount of fuse when changing fuse in the control box. [Inside Control Box] ① -250V 15A : Fuse for jump solenoid ②...

  • Page 120: 9-3) Standard Voltage For X, Y Drivers (By Machine Type)

    9-3) STANDARD VOLTAGE FOR X, Y DRIVERS (BY MACHINE TYPE) Each machine has different structures and capacities of X, Y drivers. Refer to the table below for optimal settings for each machine type. Voltage setting SWF Embroidery Machine Series Reference SWF/ –...

  • Page 121: Maintenance And Inspection

    CHAPTER MAINTENANCE AND INSPECTION 10-1) CHECK POINTS FOR REGULAR INSPECTION Safety rules must be observed during the inspection. CAUTION ① Clean, oil, and grease the set parts of the machine on a regular basis. ② Inspect tension of each driver belt. ③...
  • Page 122 Hook Guide rail to the take-up lever Fixed blade Movable blade [Fig.10-1] 10-2...

  • Page 123: 10-3) Oil Supply

    10-3) OIL SUPPLY Make sure to turn the power OFF during oil supply. CAUTION Sun Star is not responsible for machine damages or wear-outs caused by insufficient oiling. CAUTION 1) Oil supply Use the SWF sewing machine oil (Spindle Oil) or ISO-standard VG18. 2) Manual oil supply Where to Oil Oiling cycle...
  • Page 124 3) Oiling ① Cored drip-feed lubrication [Standard Type] ㉠ Location and Cycle of Oiling Oiling cycle Where to oil Inside arm a. driver pin of take-up lever Once in 2 days b. driver pin of presser foot c. driver shaft of needle bar [Fig.10-3] [CAUTION] •...
  • Page 125 ② Oiling via Pump [Option Type] ㉠ Location and Cycle of Oiling Oiling cycle Reference Fig. Where to oil Needle bar Inside arm Twice a day a. driver pin of take-up lever b. driver pin of presser foot c. driver shaft of needle bar Oil tank cover CLOSE...
  • Page 126 ③ Grease supply Make sure to turn OFF the main power during the grease supply. CAUTION Use high-quality mineral-based lithium grease. Where to Grease Greasing cycle Reference Fig. Inside the arm ① Take-up lever drive cam Once in 3 months ②...
  • Page 127 Turn OFF the main power during the grease supply. CAUTION Use lithium-type grease (JIS No.2) - Albania No.2. Where to Grease Greasing cycle Reference Fig. Once in 2 months X-axis LM guide (2 on each side) Once in 2 months Y-axis LM guide (2 on each side) Once in 2 months Sub Y drive LM guide (1 on one side)

  • Page 128: 10-4) Drive Belt Tension

    10-4) DRIVE BELT TENSION Turn OFF the main power when inspecting drive belt tension. CAUTION Too weak or too tight tension on the drive belt may cause machine malfunction or damages (abnormal wear-out of drive unit). Inspect the driver belt on a regular basis. Location for inspection Inspection cycle Reference...

  • Page 129: Chapter 11 Machine Adjustments

    CHAPTER MACHINE ADJUSTMENTS Turn OFF the main power when adjusting the machine. WARNING 11-1) ADJUSTING THE TRIMMERS 11-1-1) Adjusting the Position of the Trimming Cam (Insert Angle of Movable Blade) The movable blade is started by the trimmer cam in the angle it is inserted. As one of the basic trimming functions, it arranges the upper thread tails in the needle after trimming.

  • Page 130: 11-1-2) Adjusting Blade Tension

    11-1-2) Adjusting Blade Tension Make sure to check and adjust the cross-tension of the movable and the fixed blades after replacement or repair. ① Checking the cross tension Manually move the movable blade and cut the upper Movable blade and the lower threads. Check the cross-section of the thread cut.

  • Page 131: 11-3) Adjusting Upper Thread Holding Unit

    11-3) ADJUSTING UPPER THREAD HOLDING UNIT 1) Checking the assembly of upper thread holding lever and upper thread holder plate ① Stroke of the upper thread holder driver plate in the upper thread holder base should be 1mm from the base when the upper thread holding solenoid is on.

  • Page 132: 11-4) Picker Adjustment

    11-4) PICKER ADJUSTMENT If the position or the starting height of the picker is incorrect, the machine may not be able to separate the upper and the lower thread and cut them both, resulting in short upper thread. ① Adjusting the picker position Manually move the picker so it touches the bobbin.

  • Page 133: 11-5) Adjusting Upper Thread Holder

    11-5) ADJUSTING UPPER THREAD HOLDER Wiper return sensor ① Adjusting the sensor springs (when wiper does not return) Ⓐ Open the wiper motor cover. Of the two sensor rings, align the center of the rear sensor spring with #1 carve on the block Rear sensor spring on the shaft.

  • Page 134: 11-6) Adjusting Low-Noise Presser Foot

    11-6) ADJUSTING LOW-NOISE PRESSER FOOT 1) Assembly of Presser Foot Cam ① Set the main shaft at 178° and install two reference pins (ф3) into the assembly hole of the presser foot driver cam (ф3) as shown in [Fig.11-12]. Insert the pins then into the assembly hole of the take-up lever driver cam.

  • Page 135: 11-7) Relationship Between Presser Foot And Needle

    2) Adjusting the Height of the Presser Foot ① Check the relationship between the presser foot and the needle/embroidery material. Turn the main shaft lever to position the needle at the lowest point (178°). Remove the head cover and Presser foot Screw unfasten the screws on the presser foot so it holder...

  • Page 136: 11-8) Correct Position Of Needle

    11-8) CORRECT POSITION OF NEEDLE ① Make sure to check the position of the needle - it may change during machine delivery or leveling. First check if the needle is bent. Then turn the main shaft lever to set the shaft at around 130°. Position the needle at the lower dead stop and check if the needle is at the center of the needle hole on the plate.

  • Page 137: 11-9) Adjusting Half-Turn Film For Color Change

    11-9) ADJUSTING HALF-TURN FILM FOR COLOR CHANGE ① (For automatic color change) If the needle is not at the center of the needle hole on the plate, turn the lever and adjust so that the roller is on the center of the color change cam on the straight line. Open the cover of the half- turn sensor and align the center of the half-turn sensor with the center of the film (see [Fig.11-18(a)]).

  • Page 138: 11-11) Jump Motor Adjustment

    11-11) JUMP MOTOR ADJUSTMENT Adjustment is required for new or malfunctioning jump motor. 1) Adjusting the Standby Position (adjusting Jump crank roller motor base) ① Unscrew motor base ([Fig.11-20]) and adjust so that the jump crank roller is 0.3mm 0.3mm away from the controller. Fasten the screw.

  • Page 139: 11-12) Adjusting Drive Belt Tension

    11-12) ADJUSTING DRIVE BELT TENSION 11-12-1) Y-Axis Timing Belt [CAUTION] Specification of Drive Belt Tension Adjuster Model: U-305 Series Sound Wave Belt Tension Gauge - Standard Manufacturer: UNITTA [CAUTION] Drive belt tension can be adjusted only by trained SWF engineers. Make sure to turn OFF the machine during the adjustment.

  • Page 140: 11-12-2) X-Axis Timing Belt

    11-12-2) X-Axis Timing Belt ① Push the frame plate fully to the right ([Fig.11-22]). Check the drive belt tension on X-axis using the sound wave tension gauge. ② Tension on the X-axis timing belt should measure as below on the sound wave measurer when you pluck the middle of the belt with your finger.

  • Page 141: 11-13) Lamp (Optional)

    11-13) LAMP (OPTIONAL) 11-13-1) Lamp Socket Adjustment (4-head) Standard lamp for SWF machines measures 580mm in length. If you have to use 590mm lamp for certain purposes, adjust the lamp in the following order. ① Unfasten the three screws on the socket. ②...

  • Page 142: Chapter 12 Troubleshooting

    CHAPTER TROUBLESHOOTING DANGER CAUTION Inspect/repair the machine by the guideline when in machine failures. Error Type Cause Inspection & Repair Reference Operation failure Loose belt tension / belt Adjust belt tension / change belt See 11-9) damage Power failure or short-circuit Check fuse in main shaft motor of fuse and change fuse...
  • Page 143 Error Type Cause Inspection & Repair Reference Bad Color ① Incorrect position of needle Refer to user’ s manual Set main shaft angle back at Change stop 100° , if you manually moved it for cleaning, inspection or repair. ② Failure to sense signals for Run manual color change and See 11-9) needle position or 1 rotation...
  • Page 144 Error Type Cause Inspection & Repair Reference Poor detection Poor connection of take- Clean the spring and the plate, of upper thread up spring and thread or adjust the spring tension. detector plate Poor connection & quality Check the plate connection and of tension adjusting plate change the circuit board Short-circuit of fuse for...
  • Page 145 Error Type Cause Inspection & Repair Reference Thread breaks Stitch is too small/dense Re-punch design tape Check design for thread Frequent thread break in Re-punch after checking See 7-4-6) the same spot design Correct the stitches on operation box Inadequate needle size Change needle See 5-13)-1) for thread...
  • Page 146 Error Type Cause Inspection & Repair Reference Bad thread (weak, Change thread uneven thickness, poorly Check the thread used. twisted, old) How to select thread. •Select soft thread with ever thickness and stable tension. •Choose left-twisted thread. Right-twisted thread Change to left-twisted thread Z-direction: left twist S-direction: right twist left-twist prevents...
  • Page 147 Error Type Cause Inspection & Repair Reference Dent on thread path on Remove dent or change the hook and bobbin case case Narrow space between Adjust space Set it at 0.5-0.7mm for hook holder and groove smooth feeding of upper for hook holder (on hook) thread Insufficient oil in hook...
  • Page 148 Error Type Cause Inspection & Repair Reference Skipped Bent needle Stitches Inadequate needle size Change needle See 5-13) for thread Incorrect installation of Adjust installation needle Poor timing of needle and Adjust timing hook Large gap between needle groove and hook point Incorrect lower dead stop Adjust the lower dead stop...
  • Page 149 Error Type Cause Inspection & Repair Reference Poor stitch Weak upper thread Adjust tension See 5-7)-2) tension tension Uneven upper thread Clean main and sub tension tension due to foreign adjusters in the thread tension substances adjusting plate Weak lower thread Adjust tension See 5-8)-2) tension...
  • Page 150 Error Type Cause Inspection & Repair Reference Puckering Excessive thread tension Adjust tension See 5-7) Excessive pressure of Change presser foot spring presser foot Needle failure - Change needle worn out/damaged needle tip needle is too large for thread Needle hole is too large Use adequate size of needle SWF/ needle holes...
  • Page 151 Error Type Cause Inspection & Repair Reference Trimmer return Poor connection of sensor Check connection failure Bad circuit board Change circuit board Bad sensor or sensor change sensor See 11-2) position. clean around the sensor Dirty area around the adjust location of the sensor sensor.
  • Page 152 Error Type Cause Inspection & Repair Reference Short upper Upper thread is trimmed check upper thread tension The default is Medium thread after too short and comes Long Medium length See 7-5)-3) trimming unthreaded of trimmed thread in data set- Upper thread is trimmed Medium Short...

  • Page 153: Chapter 13 Block Diagram

    CHAPTER BLOCK DIAGRAM 1) BLOCK DIAGRAM OF SWF/C-U SERIES (Excluding SWF/C-UH 1508-45) 13-1...
  • Page 154 2) Block Diagram of SWF/C-UH1508-45 13-2...
