USER ' ' S MANUAL
INVERTING CLAMP DEVICES
SPS/A(B)-SERIES
Electronic Pattern Sewing Machine
1) FOR AT MOST USE WITH EASINESS,
PLEASE CERTAINLY READ THIS MANUAL
BEFORE STARTING USE.
2) KEEP THIS MANUAL IN SAFE PLACE
FOR REFERENCE WHEN THE MACHINE
BREAKS DOWN.
M M M M E E - - 1 1 2 2 0 0 8 8 3 3 1 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPS/B-1507 Series and is the answer not in the manual?

Questions and answers

Related Manuals for SunStar SPS/B-1507 Series

Summary of Contents for SunStar SPS/B-1507 Series

  • Page 1 USER ’ ’ S MANUAL INVERTING CLAMP DEVICES SPS/A(B)-SERIES Electronic Pattern Sewing Machine 1) FOR AT MOST USE WITH EASINESS, PLEASE CERTAINLY READ THIS MANUAL BEFORE STARTING USE. 2) KEEP THIS MANUAL IN SAFE PLACE FOR REFERENCE WHEN THE MACHINE BREAKS DOWN.
  • Page 2 1. Thank you for purchasing our product. Based on the rich expertise and experience accumulated in industrial sewing machine production, SUNSTAR will manufacture industrial sewing machines, which deliver more diverse functions, high performance, powerful operation, enhanced durability, and more sophisticated design to meet a number of user’s needs.

  • Page 3: Table Of Contents

    I. Pneumatic Control Mechanism (SPS/B-1507HJ) ............... 42 Attachments 1. Pneumatic circuit diagram for SPS/A-1306 series turnover device ......42 2. Pneumatic circuit diagram for SPS/A-1811 series turnover device ......48 3. Pneumatic circuit diagram for SPS/B-1507 series turnover device ......52...

  • Page 4: Notice Before Using

    Notice Before Using 1) Before inputting air pressure by air pressure control devices, check if a needle is not attached. If the up-feed plate and reversal feeding frame ascend simultaneously with air pressure input so that a needle is put over the reversal feeding frame, the needle can be broken Caution 2) Before reading patterns, check the pattern number once more.

  • Page 5: Inverting Clamp Devices Of Sps/A-1306 Series

    Inverting Clamp Devices of SPS/A-1306 Series 1. Installing the Inverting Clamp Devices 1) Remove the up-feed plate and feed plate cramp attached to feed bracket. 2) Remove the presser foot and insert the Inverting Inverting presser foot washer presser foot washer on that spot, then fasten a fixing screw. ↓...

  • Page 6: Adjusting The Wiper Parts

    2. Adjusting the Wiper Parts 1) Unfasten the crank fixing screw① when a needle is stopped upward. 2) Adjust the wiper crank ② for wiper and needle to be apart from about 40mm. 3) Fasten the wiper crank fixing screw ①. 4) Unfasten the wiper fixing screw ③...

  • Page 7: Installation And Adjustment Of Pneumatic Control Parts

    3. Installation and Adjustment of Pneumatic Control Parts Make sure that the power is turned off during parts installation and adjustment in order to prevent safety accidents. Caution A. For pneumatic type 1) Attach the pressure adjuster① to the rear side of the table leg using the screw. 2) Remove the plug③...

  • Page 8: Adjusting The Reversal Feeding Frame

    B. For electronic type 1) Attach the pressure adjuster② to the rear side of the table leg using the screw. 2) Connect the air hose③ to the quick joint socket②. 3) Assemble the quick joint socket② and the quick joint plug④. 4) Connect the air hose⑤...

  • Page 9: Removing The Inverting Clamp Devices

    3) Adjust the precise position by moving the pressure guide (A) and (B) to the arrow direction according to the available sewing range for label. As seen in the fig. 9, if the pressure guide (A) and (B) is interfered with the reversal crank since the width of label is too small, remove the pressure guide (A) and (B).

  • Page 10: Inverting Clamp Devices Of Sps/A-1811 Series

    Inverting Clamp Device of SPS/A-1811 Series 1. Installing the Inverting Clamp Devices 1) Exchange the up-feed plate and low-feed plate into up-feed plate for reversal and low-feed plate for reversal. 2) Attach the inverting clamp devices to the feed bracket as seen in the fig. 12. [ Fig.

  • Page 11: Adjusting The Inverting Presser Plate Feeding Frame

    5) For using the wiper, press the wiper operation switch ① and for not using it, press the wiper operation switch ①. Wiper On/Off Switch ① Wiper Off Wiper ON 7 7 1 1 0 0 [ Fig. 16 ] 3.

  • Page 12: Adjusting The Middle Stop Position Of Reversal Feeding Frame

    4. Adjusting the Middle Stop Position of Reversal Feeding Frame Adjust the middle for easy working stop position of reversal feeding frame to fit with the position of sewing materials. Adjust the gap between reversal feeding frame and sewing materials to be 1mm. 1) Unfasten the cylinder stroke adjusting nut ①.

  • Page 13: Adjusting The Label Guide

    6. Adjusting the Label Guide 1) Attach the label guide as seen in the fig. 19. In case of using label guide, attach the accessory sponge to the lower part of up-feed plate. Caution 2) After unfastening the fixing screw ①, adjust the position of label guide (A) to fit with the left end of label, then fasten the fixing screw ①.

  • Page 14: Sps/B-1507 Series Inverting Clamp Devices

    SPS/B-1507 Series Inverting Clamp Devices 1. Specifications Division SPS/B-1507HJ-23 (Direct Motor, Mobile Reversal Unit) Sewing area X(Horizontal) * Y (Longitudinal) : 150mm x 70mm Sewing speed Maximum 2,500spm (width of stitch: less than 3mm) Width of stitch 0.1~12.7mm Using needle...

  • Page 15: Structure Of Unit

    2. Structure of unit ⑤ ⑧ ④ ⑥ ① ⑨ ⑦ ③ ⑪ ② ⑩ [ Fig. 22 ] ① Reversal base/ presser ⑦ Sewing material clamp cylinder ② Reversal rotation crank ⑧ Slider base/ holder ③ Reversal rotation cylinder ⑨...

  • Page 16: Installation Of Machine

    3. Installation of machine To the face plate presser plate 1) How to attach presser plate sheet 17.8mm Attach the presser plate sheet on the side which slider base and presser plate are met as shown the Picture. ② ① Presser plate sheet [ Fig.
  • Page 17 5) How to control operating speed of reversal unit Turn clockwise the knob② of speed controller① of Solenoid valve attached to the lower part of table as shown in the below picture in order to lower the speed. Turning counterclockwise is to accelerate the speed.

  • Page 18: The Use Of Inverting Functions

    The Use of Inverting Functions They are used when inverting clamp devices are available. During programming the patterns, pay attention to that inverting clamp is interfered with needle bar, or inverting cylinder drive part is interfered with needle bar. There are two ways for inputting inverting codes (the orders to drive inverting devices), one is to call the already programmed pattern to add the inverting codes and the other is to program newly.
  • Page 19 ⑥ After pressing CODE key, set up the 2nd origin by pressing digit keys, [0][0][1]. < F u n c t i o n C o d e > C O D E N o : 0 0 1 ⑦ Press ENTER key. S E C - O R G N O N E X:?????A N:000??
  • Page 20 ⑬ After pressing CODE key, input the inverting code by pressing digit keys [0][4]and [9]. < F u n c t i o n C o d e > C O D E N o : 0 4 9 ⑭ Press ENTER key. Operate the inverting cylinder by 0 4 9 : R E V S E T pressing digit key, 1.

  • Page 21: Adding The Codes For Reversal To The Patterns Already Programmed

    ⒗ Perform test sewing. (21) After pressing WRITE key, input the number you 0 1 5 : P T R N W R I T E want to save by using digit keys, and press N O : 5 5 1 ENTER key.
  • Page 22 ⑦ Press ENTER key. Operate the inverting cylinder by pressing digit key 0 4 9 : R E V S E T P O S : 1 [ 0 / 1 ] ⑧ After confirming, press ENTER key to input the R E V S E T inverting code.

  • Page 23: Parts Book

    해당 기종의 파츠북을 조회할 수 있습니다. ㆍ파츠북은 관계별로 구분되어 있으며 관계를 알고 있다면 부품 찾기가 용이합니다. ㆍYou can make an order for the parts of Sunstar machine to connect internet address. http://www.sunstarcs.com ㆍYou can request for parts you want after login if you are a registered member.

  • Page 24: Inverting Clamp Devices Mechanism (Sps/A-1306 Series)

    Inverting Clamp Devices Mechanism ( SPS/A-1306 Series ) A-22 A-18 A-23 A-17 A-19 A-21 A-12 A-16 A-13 A-20 A-24 A-12 A-14 A-13 A-16 A-24 A-10 A-28 A-11 A-15 A-25, A-26 A-27...
  • Page 25 Applied Ref. No. Parts No. Note Name of Parts 품 명 Q’ ty Period GP-036450-00 Inverting Base 반전 베이스 GP-048392-00 Inverting Crank 반전 크랭크 Jan.25.09 52A002S-306H Inverting Crank 반전 크랭크 DSC-BJ004800 Screw (1/8” n=40) 죔나사(1/8” n=40) SW-0103-9011 Washer 와셔 52A005S-306H Inverting Crank Base 반전...

  • Page 26: Inverting Clamp Devices Mechanism (Sps/A-1811 Series)

    Inverting Clamp Devices Mechanism ( SPS/A-1811 Series ) B-12 B-41 B-34 B-10 B-42 B-13 B-39 B-11 B-10 B-14 B-27 B-33 B-37 B-15 B-28 B-26 B-16 B-29 B-16 B-32 B-17 B-14 B-38 B-18 B-21 B-14 B-22 B-19 B-31 B-20 B-30 B-40 B-36 B-23 B-24,25...
  • Page 27 Applied Ref. No. Parts No. Note Name of Parts 품 명 Q’ ty Period GP-048393-00 Inverting Crank 반전크랭크 Jan.25.09 09-A017S-811H Inverting Crank 반전크랭크 09A026S-811H Inverting Rack 반전 랙 09A021S-811H Inverting Clamp Shaft Base 반전 클램프 축 베이스 09A011S-811H Inverting Clamp Spacer 반전...

  • Page 28: Wiper & Presser Foot Mechanism

    Wiper & Presser Foot Mechanism C-19 C-20 C-21 C-18 C-17 C-10 C-12 C-11 C-13 C-12 C-12 C-14 C-15 C-16...
  • Page 29 Applied Ref. No. Parts No. Note Name of Parts 품 명 Q’ ty Period 11S036S-306H Wiper On/Off Switch Ass’ y 와이퍼 작동 스위치(조) 1Set 09A004S-811H Wiper Cover 와이퍼 커버 SC-0543-4525 Screw (0.46mm n=40) 죔나사 09A005S-811H Wiper Base 와이퍼 베이스 SC-0525-4122 Screw (0.46mm n=40) 죔나사...

  • Page 30: Pneumatic Control Mechanism (Sps/A-1306 Pneumatic Machine Seires)

    Pneumatic Control Mechanism ( SPS/A-1306 Pneumatic Machine Seires ) D-12 D-13 D-10 D-14 D-15 D-11...
  • Page 31 Applied Ref. No. Parts No. Note Name of Parts 품 명 Q’ ty Period 49A001S-811H Urethane Hose (ф4) 우레탄 호스 (ф4) 05A052S-811H Urethane Hose (ф6) 우레탄 호스 (ф6) 49A006S-811H Regulator 압력 조정기 49A009S-811H 티 49A014S-811H Elbow Union 엘보우 유니온 02031SC-2113 Screw (M5×P0.8) 죔나사...

  • Page 32: Pneumatic Control Mechanism (Sps/A-1306 Electronic Machine Series)

    Pneumatic Control Mechanism (SPS/A-1306 Electronic Machine Series) E-20 E-19 E-18 E-17 E-16 E-15 E-13 E-12 E-10 E-11 E-14...
  • Page 33 Applied Ref. No. Parts No. Note Name of Parts 품 명 Q’ ty Period 49A004S-811H Quick Joint Plug Ass’ y 퀵 조인트 플러그 49A005S-811H Finger Valve 핑거 밸브 49A006S-811H Filter Regulator 압력 조정기 49A008S-811H Screw(M5×P0.8) 고정나사 10-010W-7507 Washer 와셔 49A009S-811H Nut (M5×P0.8) 너트...

  • Page 34: Pneumatic Control Mechanism (Sps/A-1811 Series)

    Pneumatic Control Mechanism ( SPS/A-1811 Series )
  • Page 35 Applied Ref. No. Parts No. Note Name of Parts 품 명 Q’ ty Period 49A001S-811H Urethane Hose (ф4) 우레탄 호스 (ф4) 49A017S-811H Solenoid valve 솔레노이드 밸브 51A048S-81H2 Manifold Block 메니폴드 블럭 49A013S-811H Straight Union 스트레이트 유니온 49A100S-811H Check Valve 체크 밸브 49A015S-811H Hose Nipple 호스...

  • Page 36: Inverting Clamp Devices Mechanism (Sps/A-2516 Series)

    Inverting Clamp Devices Mechanism ( SPS/A-2516 Series) G-41 G-40 G-43 G-10 G-38 G-11 G-12 G-23 G-36 G-22 G-13 G-37 G-25 G-41 G-14 G-40 G-14 G-24 G-34 G-28 G-15 G-43 G-12 G-45 G-16 G-29 G-17 G-32 G-39 G-27 G-44 G-18 G-41 G-26 G-42 G-19...
  • Page 37 Applied Ref. No. Parts No. Note Name of Parts 품 명 Q’ ty Period GP-048393-01 Inverting Crank 반전크랭크 Mar.08.12 GP-048393-00 Inverting Crank 반전크랭크 Jan.25.09 09A017S-811H Inverting Crank 반전크랭크 09A026S-811H Inverting Rack 반전 랙 09A021S-811H Inverting Clamp Shaft Base 반전 클램프 축 베이스 09A011S-811H Inverting Clamp Spacer 반전...

  • Page 38: Inverting Clamp Devices Mechanism (Sps/B-1507Hj)

    Inverting Clamp Devices Mechanism (SPS/B-1507HJ) H-38 H-39 H-17 H-37 H-36 H-35 H-17 H-33 H-34 H-30 H-32 H-40 H-31 H-27 H-23 H-22 H-41 H-29 H-42 H-26 H-25 H-42 H-24 H-21 H-17 H-18 H-28 H-43 H-16 H-20 H-43 H-19 H-15 H-55 H-15 H-48 H-11 H-56...
  • Page 39 Applied Ref. No. Parts No. Note Name of Parts 품 명 Q’ty Period CCP-BB039600 Presser Plate 누름판 DSC-BB008100 Screw(3/16" n=32) 접시 작은나사 DSC-AA003100 Bolt(3/16" n=32, L=10) 육각 볼트 CPR-LF000200 Presser Plate Coating Film 누름판 코팅 필름 DGR-AF002600 Rack Gear 랙 기어 CCP-BJ014600 Inverting Crank Washer 반전...
  • Page 40 Inverting Clamp Devices Mechanism (SPS/B-1507HJ) H-38 H-39 H-17 H-37 H-36 H-35 H-17 H-33 H-34 H-30 H-32 H-40 H-31 H-27 H-23 H-22 H-41 H-29 H-42 H-26 H-25 H-42 H-24 H-21 H-17 H-18 H-28 H-43 H-16 H-20 H-43 H-19 H-15 H-55 H-15 H-48 H-11 H-56...
  • Page 41 Applied Ref. No. Parts No. Note Name of Parts 품 명 Q’ ty Period H-48 PSC-AC013000 Bolt (M4xP0.7,L=8) 육각구멍붙이 볼트 H-49 CCP-BB044201 Guide Locking Block C 가이드 록킹 블록 C H-50 PPP-CA009800 Air Cylinder 에어 실린더 H-51 PPP-AA001100 Fitting (KJL04-M5) 피팅...

  • Page 42: Pneumatic Control Mechanism (Sps/B-1507Hj)

    Pneumatic Control Mechanism (SPS/B-1507HJ) I-14 I-23 I-18 I-24 I-20 I-22 I-21 I-15 I-16 I-19 I-17 I-25 I-12 I-11 I-13 I-10...
  • Page 43 Applied Ref. No. Parts No. Note Name of Parts 품 명 Q’ ty Period AAR-PS000200 Filter Regulator Assembly 필터레귤레이터(조) PPP-AG000100 Finger Valve 핑거 밸브 PPP-BD000100 Filter Regulator 필터레귤레이터 PPP-BG000100 Air Pressure Switch 공압 스위치 PPP-AA000400 Fitting 피팅 PPP-AA000500 Fitting 피팅 DSC-HB000700 Stud Screw 원형...

  • Page 44: Attachments

    Attachments 1. Pneumatic circuit diagram for SPS/A-1306 series turnover device 1) SPS/A-1306-HS-10 7 7 4 4 4 4...
  • Page 45 2) SPS/A-1306-HS-20 7 7 4 4 5 5...
  • Page 47 4) SPS/A-1306-HS-23(SPS/A-1306-HS-22) 7 7 4 4 7 7...

  • Page 52: Pneumatic Circuit Diagram For Sps/B-1507 Series Turnover Device

    3. Pneumatic circuit diagram for SPS/B-1507 series turnover device 1) SPS/B-1507-HJ-23 Feed Frame Cyl’d Inverting Rotating Cyl’d Inverting Clamp Cyl’ d Inverting Moving Cyl’ d AIR IN → 7 7 5 5 2 2...
  • Page 53 7 7 5 5 3 3...
